RM300 Road Reclaimer
US
Metric
Overview
The RM300 combines superior performance and reliability to achieve the most demanding job specifications while maximizing machine uptime. With many enhanced features and options, the RM300 is designed to work well in both full depth reclamation and soil stabilization applications.
Weights
Maximum Operating Weight
53911.00 lb
24454.00 kg
Operating Specifications
Cutting/Mixing Width
96.00 in
2438.00 mm
Maximum Cutting/Mixing Depth
20.00 in
508.00 mm
Maximum Travel Speed
6.00 mile/h
9.70 km/h
Operating Speed
2.70 mile/h
4.30 km/h
Rotor Options
Universal, Combination, Spade
Rotor Speed - First (at 2100 Engine rpm)
106.00 r/min
106.00 r/min
Rotor Speed - Second (at 2100 Engine rpm)
144.00 r/min
144.00 r/min
Rotor Speed - Third (at 2100 Engine rpm)
216.00 r/min
216.00 r/min
Engine
Gross Power
350.00 HP
261.00 kW
Engine Model
C11 with ACERT
Dimensions
Ground Clearance
28.30 in
720.00 mm
Length
32.83 ft
10.00 m
Maximum Height
11.08 ft
3.37 m
Wheel Base
20.75 ft
6.32 m
Width
9.83 ft
3.00 m
Service Refill Capacities
Fuel Tank Capacity
279.00 gal (US)
1056.00 l
Features
C11 Engine with ACERT® Technology
Operator's Station
Operational Controls
Sliding Cab (Optional)
Electronic Control Modules
Propel System
Rear Wheel Drive (Optional)
Rotor Drive
Mixing Chamber
Hydraulic Front Door (Optional)
Universal Rotors
Combination Rotor
Spade Rotor
Serviceability
Sales Features
C11 Engine with ACERT® Technology
A combination of innovations working at the point of combustion, ACERT® Technology optimizes engine performance while meeting U.S. EPA Tier 3 and European EU Stage IIIa emission regulations for off-road applications.Operator’s Station
Ergonomic design emphasizes operator comfort, visibility and easy operation. The optional sliding platform slides side-to-side to reduce operator fatigue for increased productivity.Operational Controls
All machine controls, switches and gauges are positioned to minimize operator fatigue and maximize productivity.Sliding Cab (Optional)
Optional cab can increase machine utilization and provides greater year-round comfort in extreme environment conditions. The cab is fully pressurized and includes air conditioning.Electronic Control Modules
Reliable field-proven technology makes machine operation simple and self-diagnostics simplifies troubleshooting.Propel System
Hydrostatic drive provides balanced tractive effort to each drive motor.Rear Wheel Drive (Optional)
Optional rear wheel drive includes a separate hydraulic pump and large displacement motors on each rear wheel. The system propels the machine with all-wheel drive.Rotor Drive
Maximum production with high reliability. The mechanical rotor drive system provides three rotor speeds for maximum performance in a variety of materials and cutting depths.Mixing Chamber
Mixing chamber is a heavy-duty hood with large volume to handle deep mixing. Ensures depth control, proper sizing and thorough blending of reclaimed materials.Hydraulic Front Door (Optional)
Optional front door is ideal for peak efficiency on soil stabilization, bio-remediation or mixing passes on asphalt reclamation.Universal Rotors
Two universal rotors for different tasks.Combination Rotor
Designed primarily for soil stabilization applications in cohesive soils.Spade Rotor
Designed for soil stabilization applications.Serviceability
Less time on maintenance means more time on the job.Optional Equipment
- Roll Over Protective Structure (ROPS)
- Falling Object Protective Structure (FOPS)
- Sliding Operator Station
- Sliding Cab
- Rear Wheel Drive
- Automatic Rotor Depth Control
- Four Mode Steering
- Hydraulically Operated Front Door
- Friction Torque Limiter
- Working Light Package
- Roading Light Package
- Warning Beacon Light
- Mirror Package
- Umbrella
- Water Spray System
- Powertrain Guard
- Universal Rotor
- Soil Rotor
