Cat® D6N WH Waste Handler

Request A Quote D6N WH Attachments New and Used Inventory
D6N WH Waste Handler
No video provider was found to handle the given URL. See the documentation for more information.
US
Metric

Overview

From pushing trash to spreading cover, and cell construction to closing, Cat® Waste Handlers are designed and manufactured from the frame up to take on the demands of landfill work.

Engine

Engine Model
Cat C7.1 ACERT™
Flywheel Power
182.00 hp
136.00 kW
Emissions
Tier 4 Final/Stage IV/Korea Tier 4 Final
Net Power (Rated – 1,800 rpm): ISO 9249/SAE J1349
166.00 hp
124.00 kW
Net Power (Rated – 1,800 rpm): ISO 9249/SAE J1349 (DIN)
168.00 hp
124.00 kW
Net Power (Maximum – 2,200 rpm): SAE J1995
182.00 hp
136.00 kW
Net Power (Maximum – 2,200 rpm): ISO 14396
178.00 hp
133.00 kW
Bore
4.10 in
105.00 mm
Stroke
5.30 in
135.00 mm
Displacement
433.00 in3
7.10 L

Weights

Operating Weight
40818.00 lb
18515.00 kg
Operating Weight – XL Waste Handler
40818.00 lb
18515.00 kg
Operating Weight – LGP Waste Handler
44749.00 lb
20298.00 kg
Shipping Weight – XL Waste Handler
40029.00 lb
18157.00 kg
Shipping Weight – LGP Waste Handler
43642.00 lb
19796.00 kg

Blades – Capacity (SAE J1265)

XL VPAT Landfill*
8.29 yd3
6.34 m3
XL VPAT
4.30 yd3
3.30 m3
XL SU
5.60 yd3
4.30 m3
LGP VPAT Landfill*
7.39 yd3
5.65 m3
LGP VPAT
5.10 yd3
3.90 m3
Note
*Blade capacity with trash rack.

Dimensions – XL

Track Gauge
74.40 in
1890.00 mm
Width of Tractor (without trunnions)
98.40 in
2500.00 mm
Machine Height from Tip of Grouser to Exhaust Stack
122.40 in
3108.00 mm
Length of Track on Ground
101.60 in
2581.00 mm
Length of Basic Tractor (with drawbar)*
157.30 in
3995.00 mm
Height of Grouser
2.60 in
66.00 mm
Ground Clearance
14.30 in
364.00 mm
Ground Pressure
6.70 psi
46.10 kPa
Note
*Add 1185 mm (46.7 in) to length of basic tractor (with drawbar) with SU blade added. Add 957 mm (37.7 in) to length of basic tractor (with drawbar) with ripper (with tip at ground line).

Dimensions – LGP

Track Gauge
85.00 in
2160.00 mm
Width of Tractor (without trunnions)
118.00 in
3000.00 mm
Machine Height from Tip of Grouser to Exhaust Stack
126.90 in
3222.00 mm
Length of Track on Ground
122.70 in
3110.00 mm
Length of Basic Tractor (with drawbar)*
166.20 in
4222.00 mm
Height of Grouser
2.20 in
57.00 mm
Ground Clearance
18.80 in
477.00 mm
Ground Pressure
4.50 psi
31.20 kPa
Note
*Add 957 mm (37.7 in) to length of basic tractor (with drawbar) with ripper (with tip at ground line).

Engine

Note
All non road Tier 4, Stage IIIB and IV, and Korea Tier 4 Final diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm (EPA), 10 ppm (EU) (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations.
Note
Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241.

Transmission

0.5 Forward
1.60 mph
2.50 km/h
0.7 Forward
1.70 mph
2.80 km/h
1.0 Forward
2.10 mph
3.30 km/h
1.5 Forward
2.70 mph
4.40 km/h
1.7 Forward
3.00 mph
4.90 km/h
2.0 Forward
3.60 mph
5.80 km/h

Engine

Net Power - Maximum - ISO 14396 (DIN) at 2,200 rpm
180.00 HP
133.00 kW

Blades - Width - Over End Bits

XL VPAT Landfill*
10.23 ft
3120.00 mm
XL VPAT
10.75 ft
3272.00 mm
XL SU
10.33 ft
3154.00 mm
LGP VPAT - Landfill*
12.89 ft
3929.00 mm
LGP VPAT
13.38 ft
4080.00 mm
Note
*Blade capacity with trash rack.

Transmission

2.5 Forward
4.70 mph
7.50 km/h
2.7 Forward
5.20 mph
8.30 km/h
3.0 Forward
6.10 mph
9.80 km/h
0.5 Reverse
1.90 mph
3.10 km/h
0.7 Reverse
2.10 mph
3.40 km/h
1.0 Reverse
2.50 mph
4.10 km/h
1.5 Reverse
3.40 mph
5.40 km/h
1.7 Reverse
3.70 mph
6.00 km/h
2.0 Reverse
4.40 mph
7.10 km/h
2.5 Reverse
5.90 mph
9.50 km/h
2.7 Reverse
6.50 mph
10.50 km/h
3.0 Reverse
7.60 mph
12.20 km/h

Engine

Note
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes.
Engine Model
Cat C7.1 ACERT™
Flywheel Power
182.00 HP
136.00 kW
Bore
4.10 in
105.00 mm
Stroke
5.30 in
135.00 mm
Displacement
433.00 in³
7.10 l
Net Power - 1,800 rpm - ISO 9249/SAE J1349
166.00 HP
124.00 kW
Net Power - 1,800 rpm - ISO 9249/SAE J1349 (DIN)
168.00 HP
124.00 kW
Net Power - Maximum - ISO 14396 at 2,200 rpm
178.00 HP
133.00 kW
Net Power - Maximum - SAE J1995 at 2,200 rpm
182.00 HP
136.00 kW

Weights

Operating Weight
40818.00 lb
18515.00 kg
Operating Weight - LGP Waste Handler
44749.00 lb
20298.00 kg
Operating Weight - XL Waste Handler
40818.00 lb
18515.00 kg
Shipping Weight - LGP Waste Handler
43642.00 lb
19796.00 kg
Shipping Weight - XL Waste Handler
40029.00 lb
18157.00 kg

Dimensions - LGP

Ground Clearance
18.80 in
477.00 mm
Ground Pressure
4.50 psi
31.20 kPa
Height - Grouser
2.20 in
57.00 mm
Length - Basic Tractor - With Drawbar*
166.20 in
4222.00 mm
Length - Track on Ground
122.70 in
3110.00 mm
Machine Height - Grouser Tip - Exhaust Stack
126.90 in
3222.00 mm
Note
*Add 957 mm (37.7 in) to length of basic tractor (with drawbar) with ripper (with tip at ground line).
Track Gauge
85.00 in
2160.00 mm
Width - Tractor - Without Trunnions
118.00 in
3000.00 mm

Dimensions - XL

Ground Clearance
14.30 in
364.00 mm
Ground Pressure
6.70 psi
46.10 kPa
Height - Grouser
2.60 in
66.00 mm
Length - Basic Tractor - With Drawbar*
157.30 in
3995.00 mm
Length - Track on Ground
101.60 in
2581.00 mm
Machine Height - Grouser Tip - Exhaust Stack
122.40 in
3108.00 mm
Note
*Add 1185 mm (46.7 in) to length of basic tractor (with drawbar) with SU blade added. Add 957 mm (37.7 in) to length of basic tractor (with drawbar) with ripper (with tip at ground line).
Track Gauge
74.40 in
1890.00 mm
Width - Tractor - Without Trunnions
98.40 in
2500.00 mm

Blades - Capacity (SAE J1265)

LGP VPAT
5.10 yd³
3.90 m³
LGP VPAT - Landfill*
7.39 yd³
5.65 m³
Note
*Blade capacity with trash rack.
XL SU
5.60 yd³
4.30 m³
XL VPAT
4.30 yd³
3.30 m³
XL VPAT Landfill*
8.29 yd³
6.34 m³

Engine

Emissions
Tier 4 Final/Stage IV/Korea Tier 4 Final
Note (1)
All non road Tier 4, Stage IIIB and IV, and Korea Tier 4 Final diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm (EPA), 10 ppm (EU) (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations.
Note (2)
Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241.
Note (3)
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes.

Transmission

0.5 Forward
1.60 mile/h
2.50 km/h
0.5 Reverse
1.90 mile/h
3.10 km/h
0.7 Forward
1.70 mile/h
2.80 km/h
0.7 Reverse
2.10 mile/h
3.40 km/h
1.5 Forward
2.70 mile/h
4.40 km/h
1.5 Reverse
3.40 mile/h
5.40 km/h
1.7 Forward
3.00 mile/h
4.90 km/h
1.7 Reverse
3.70 mile/h
6.00 km/h
2.5 Forward
4.70 mile/h
7.50 km/h
2.5 Reverse
5.90 mile/h
9.50 km/h
2.7 Forward
5.20 mile/h
8.30 km/h
2.7 Reverse
6.50 mile/h
10.50 km/h
1.0 Forward
2.10 mile/h
3.30 km/h
2.0 Forward
3.60 mile/h
5.80 km/h
3.0 Forward
6.10 mile/h
9.80 km/h
1.0 Reverse
2.50 mile/h
4.10 km/h
2.0 Reverse
4.40 mile/h
7.10 km/h
3.0 Reverse
7.60 mile/h
12.20 km/h
Features

Durability

  • Specialized guarding throughout the machine helps protect major components like the chassis, fuel tank and hydraulic tank from impact and airborne debris.
  • Multi-layer final drive guards help keep dirt and debris away from the Duo-Cone™ seal to protect final drive oil.
  • Pivot shaft seal guards to help prevent debris from entering and damaging seals.
  • Striker bars help prevent debris from damaging the machine, and added seals help reduce the amount of material entering engine and transmission compartments.
  • Tilt cylinder with rotating bushing type design help wrapping materials to roll off hoses.
  • Heavy duty hinged radiator guard protects radiator and fan from penetration by material coming straight in or from under the blade.
  • Cooling system designed for high debris environments, with automatic reversing fan and swing-out access for cleanout.
  • Laminated thermal shields and insulated Clean Emissions Module.
  • Hinged belly guard for easy cleaning.
  • Landfill blades and center-hole track shoes help you optimize your waste handler for the job.
  • Lights mounted up and away from main debris area for protection, while still giving you plenty of light on the work area.

Performance

  • New transmission with a lock-up clutch torque converter automatically selects the drive mode best suited to your application.
  • Up to 15% improvement in fuel efficiency and 10% more productivity* in most applications.
  • Enhanced Auto Shift (Standard) helps save fuel by automatically upshifting/downshifting to maintain the most efficient gear based on load. Three different settings, 3-speed, 6-speed and fine adjustment mode, allow you to optimize tractor performance for waste applications.
  • Comfortable, quiet operator station with excellent visibility and air handling features to help keep dust out/provide air filtration.
  • Low effort, responsive controls for precision and ease of operation.
  • Selectable electro-hydraulic maps let you set implement response to match operator preferences and application.
  • Rear vision camera available to enhance visibility behind the machine.
  • Meets U.S. EPA Tier 4 Final/EU Stage IV/Korea Tier 4 Final emission standards with emissions technology that is transparent – no action required from the operator, no stopping for regeneration.
*Compared to previous D6N model.

Cat Connect Technology

  • Cat GRADE with Slope Assist (Standard) automatically maintains pre-established blade angles to save time, increase finish quality and reduce operator effort, especially for cover work. Experienced operators can work more productively; less experienced operators can achieve better quality results more quickly.
  • Cat Slope Indicate (Standard) shows cross slope and mainfall on the primary machine display to help operators work more confidently.
  • Cat GRADE with 3D (Optional – available late 2016) is an integrated grade control system that helps operators grade with more accuracy and efficiency. Antennas mount on top of the cab – not on the blade – so they are safely out of the way of landfill debris.
  • Cat AccuGrade™ (Optional) machine control and guidance option helps operators improve productivity and accuracy by as much as 50% over conventional methods.
  • Cat AccuGrade Ready Option (ARO) (Optional) allows you to easily install or upgrade to Cat AccuGrade 2D and 3D grade-control systems to add versatility and resale value to your machine.
  • Remote monitoring with Product Link™/VisionLink® helps you manage your fleet more effectively and profitably.
