Overview

Grading Buckets for Cat® Mini Excavators are designed to provide optimum grading, trenching, slope-cutting and finishing work in addition to nesting additional buckets for ease of transportation.
Width
47.20 in
1200.00 mm
Capacity
9.20 ft³
259.89 l
Weight
410.50 lb
186.19 kg
Base Edge Thickness
0.80 in
20.00 mm
Tip Radius
28.20 in
715.20 mm
Interface Type
Pin On
Features

Application

Designed for cleaning ditches, sloping, grading and other finishing work.

Bucket Nesting

Transport all buckets needed for a job within the Grading Bucket.

Bolt-On Cutting Edge

Allows for smooth finish in grading applications.

Lack of Drainage Holes

Retains material and water for waste removal and light material applications.

Included Pins

Pins come pre-installed with bucket.
