826 Landfill Compactor
826 Landfill Compactor
826 Landfill Compactor
826 Landfill Compactor
826 Landfill Compactor
US
Metric

Overview

Cat landfill compactors are designed with durability built in, ensuring maximum availability through multiple lifecycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1978, the 826 has been an industry leader for over 45 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 826 continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Engine

Engine Model
C15 Cat®
Emissions
U.S. EPA Tier 4 Final/ EU Stage V/Korea Stage V and Japan 2014 or Brazil MAR-1, emitting equivalent to U.S. EPA Tier 3/EU Stage IIIA
Net Power - ISO 9249
405.00 hp
302.00 kW
Gross Power - SAE J1995
435.00 hp
324.00 kW
Torque Rise
33%
Bore
5.40 in
137.20 mm
Stroke
6.70 in
171.40 mm
Displacement
927.60 in³
15.20 l
High Idle Speed
2300.00 r/min
2300.00 r/min
Low Idle Speed
800.00 r/min
800.00 r/min
Maximum Altitude - Without Derating (Tier 3/Stage IIIA)
9098.00 ft
2773.00 m

Operating Specifications

Maximum Operating Weight (Tier 3/Stage IIIA equivalent)
91549.00 lb
41526.00 kg

Transmission

Transmission Type
Planetary - Powershift - ECPC
Direct Drive - Forward 1
4.20 mile/h
6.80 km/h
Direct Drive - Forward 2
7.50 mile/h
12.10 km/h
Direct Drive - Reverse 1
4.30 mile/h
7.80 km/h
Direct Drive - Reverse 2
8.60 mile/h
13.80 km/h

Hydraulic System

Pump Flow at 1,950 rpm
30.90 gal/min
117.00 l/min
Main Relief Pressure
3771.00 psi
26000.00 kPa
Maximum Supply Pressure
3495.00 psi
24100.00 kPa
Lift System
Double Acting Cylinder
Bore
4.70 in
120.00 mm
Stroke
42.10 in
1070.00 mm

Service Refill Capacities

Cooling System
30.60 gal (US)
116.00 l
Engine Crankcase
9.00 gal (US)
34.00 l
Transmission
17.40 gal (US)
66.00 l
Fuel Tank
206.60 gal (US)
782.00 l
Differential - Final Drives - Front
26.40 gal (US)
100.00 l
Differential - Final Drives - Rear
29.10 gal (US)
110.00 l
Hydraulic Tank Only
35.40 gal (US)
134.00 l

Axles

Front
Planetary - Fixed
Rear
Planetary - Oscillating
Oscillation Angle
±5°

Braking System

Service Brakes
Multi Disc Wet (Enclosed) 2 WHL
Parking Brake
Drum and Shoe, Spring Applied, Hydraulic Released

Sound Performance - Tier 4 Final/EU Stage V - Standard

Operator Sound Level (ISO 6396)
73.00 dB(A)
73.00 dB(A)
Machine Sound Level (ISO 6395)
113.00 dB(A)
113.00 dB(A)

Sound Performance - Tier 4 Final/EU Stage V - Suppression

Operator Sound Level (ISO 6396
72.00 dB(A)
72.00 dB(A)
Machine Sound Level (ISO 6395)
110.00 dB(A)
110.00 dB(A)

Hydraulic System - Steering

Steering System - Circuit
Pilot operated, load sensing
Bore
4.50 in
114.30 mm
Stroke
22.70 in
576.00 mm
Steering System - Pump
Piston - Variable Displacement
Maximum System Flow
170 L/min @ 1,800 rpm (44.9 gal/min @ 1,800 rpm)
Steering Pressure Limited
3481.00 psi
24000.00 kPa
Vehicle Articulation Angle
86.00 °
86.00 °

Service Refill Capacities

Diesel Exhaust Fluid Tank (Tier 4 Final/Stage IV)
8.50 gal (US)
32.00 l

Cab - Standard

Machine Sound Power Level (ISO 6395)
113.00 dB(A)
113.00 dB(A)
Operator Sound Pressure Level - ISO 6396
73.00 dB(A)
73.00 dB(A)

Cab - Suppression

Machine Sound Power Level (ISO 6395)
110.00 dB(A)
110.00 dB(A)
Operator Sound Pressure Level - ISO 6396
72.00 dB(A)
72.00 dB(A)

Dimensions (Approximate)

Height to Top of Air Conditioning Condenser
14.99 ft
4568.00 mm
Height - Cab Roof
13.75 ft
4193.00 mm
Height - Top of Beacon
15.63 ft
4765.00 mm
Height - Top of Exhaust Pipe
14.56 ft
4439.00 mm
Height - Top of Hood
10.87 ft
3312.00 mm
Ground Clearance - Bumper
3.15 ft
960.00 mm
Centerline of Rear Axle to Edge of Counterweight - No Rear Radiator Guard
9.38 ft
2860.00 mm
Centerline of Rear Axle to Edge of Counterweight - Including Rear Radiator Guard
10.16 ft
3096.00 mm
Hitch to Centerline of Front Axle
6.07 ft
1850.00 mm
Wheel Base
12.14 ft
3700.00 mm
Length - With Blade on Ground - Straight Blade - Including Rear Radiator Guard
28.59 ft
8715.00 mm
Ground Clearance
2.11 ft
642.00 mm
Width - Over Wheels
12.47 ft
3800.00 mm
Turning Radius - Inside of Wheels
9.18 ft
2797.00 mm

Wheels

Combination Tips (Weight Group)
21125.00 lb
9582.00 kg
Plus Tips - Weight (Group)
22002.00 lb
9980.00 kg
Paddle Tips - Weight (Group)
20540.00 lb
9317.00 kg
Outside Diameter
77.60 in
1971.00 mm
Drum Diameter
63.40 in
1610.00 mm
Drum Width
47.20 in
1200.00 mm
Feet Per Row
6
Feet Per Wheel
30
Replaceable
Weld On
Width Over Drums
3800.00 mm
149.60 in
Tip Height
179.00 mm
7.00 in

Engine

Gross Power - SAE J1995:2014
435.00 hp
324.00 kW
Net Power - SAE J1349:2011
405.00 hp
302.00 kW
Net Power - ISO 9249:2007
405.00 hp
302.00 kW
Engine Power - ISO 14396:2002
426.00 hp
318.00 kW
Rated Speed
1800
Note
Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator.

Operating Specifications

Operating Weight (Tier 4 Final/Stage V)
90207.00 lb
40917.00 kg
Operating Weight (Tier 3/Stage IIIA equivalent)
89186.00 lb
40454.00 kg
Maximum Operating Weight (Tier 4 Final/Stage V)
92568.00 lb
41988.00 kg

Service Refill Capacities

Note
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: • 20% biodiesel FAME (fatty acid methyl ester) * • 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer). ** Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels – Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specifications are required. – Diesel exhaust fluid (DEF) that meets all requirements defined in ISO 22241-1:2006.

Sound Performance - Tier 4 Final/EU Stage V

Operator Sound Level (ISO 6396:2008) - Standard
73.00 dB(A)
73.00 dB(A)
Machine Sound Level (ISO 6395:2008) - Standard
113.00 dB(A)
113.00 dB(A)
Operator Sound Level (ISO 6396:2008) - Suppression
72.00 dB(A)
72.00 dB(A)
Machine Sound Level (ISO 6395:2008) - Suppression
110.00 dB(A)
110.00 dB(A)
Note (1)
The operator sound pressure level was measured according to the test procedures and conditions specified in ISO 6396:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
Note (2)
The machine sound power level was measured according to the test ISO 6395:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
Note (3)
Hearing protection may be needed when operating with an open operator station and cab (when not properly maintained or doors/windows open) for extended periods or in a noisy environment.

Sound Performance - Tier 3 / Stage IIIA

Operator Sound Level (ISO 6396:2008) - Standard
73.00 dB(A)
73.00 dB(A)
Machine Sound Level (ISO 6395:2008) - Standard
113.00 dB(A)
113.00 dB(A)
Operator Sound Level (ISO 6396:2008) - Suppression
72.00 dB(A)
72.00 dB(A)
Machine Sound Level (ISO 6395:2008) - Suppression
110.00 dB(A)
110.00 dB(A)
Note (1)
* Sound suppression equipped
Note (2)
The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (3)
Hearing protection may be needed when operating with an open operator station and cab (when not properly maintained or doors/windows open) for extended periods or in a noisy environment.

Wheels

Diamond Tips Weight (Group)
23997.00 lb
10885.00 kg
Outside Diameter - Diamond
78.10 in
1983.00 mm
Tip Height - Diamond
7.25 in
179.00 mm

Engine

Peak Torque (1,300 rpm)
1479.00 lbf·ft
2005.00 N·m
Maximum Altitude – Without Derating (Tier 4 Final/Stage V)
9298.00 ft
2834.00 m

Hydraulic System

Pump Flow at 1800 rpm
30.90 gal/min
117.00 l/min

Service Refill Capacities

Diesel Exhaust Fluid Tank (Tier 4 Final/Stage V)
8.50 gal (US)
32.00 l

Straight Blade

Width – Moldboard Length
14.16 ft
4311.00 mm
Width - Over End Bits
14.75 ft
4502.00 mm
Height with Cutting Edge and Screen
6.23 ft
1900.00 mm
Maximum Depth of Cut
1.50 ft
461.00 mm
Maximum Lift above Ground
4.19 ft
1277.00 mm
Capacity, Rated
16.10 yd³
12.30 m³
Overall Machine Length (includes rear radiator guard, measured to cutting edge)
28.59 ft
8715.00 mm

Semi U-Blade

Width – Moldboard Length
14.66 ft
4462.00 mm
Width - Over End Bits
14.83 ft
4522.00 mm
Height with Cutting Edge and Screen
6.63 ft
2022.00 mm
Maximum Depth of Cut
2.03 ft
619.00 mm
Maximum Lift above Ground
3.83 ft
1165.00 mm
Capacity, Rated
20.90 yd³
16.00 m³
Overall Machine Length (includes rear radiator guard, measured to cutting edge)
29.54 ft
9005.00 mm

U-Blade

Width – Moldboard Length
14.25 ft
4331.00 mm
Width - Over End Bits
14.41 ft
4398.00 mm
Height with Cutting Edge and Screen
6.62 ft
2019.00 mm
Maximum Depth of Cut
2.03 mm
619.00 mm
Maximum Lift above Ground
3.79 ft
1156.00 mm
Capacity, Rated
22.90 yd³
17.50 m³
Overall Machine Length (includes rear radiator guard, measured to cutting edge)
30.70 ft
9357.00 mm

Sound Performance - Tier 4 Final / Stage V

Operator Sound Pressure Level (ISO 6396:2008)
73.00 dB(A)
73.00 dB(A)
Machine Sound Power Level (ISO 6395:2008)
113.00 dB(A)
113.00 dB(A)
Operator Sound Pressure Level (ISO 6396:2008)*
72.00 dB(A)
72.00 dB(A)
Machine Sound Power Level (ISO 6395:2008)*
110.00 dB(A)
110.00 dB(A)
Note (1)
* Sound suppression equipped
Note (2)
The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (3)
The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (4)
Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.

Sound Performance - Tier 3 / Stage IIIA

Operator Sound Pressure Level (ISO 6396:2008)
73.00 dB(A)
73.00 dB(A)
Machine Sound Power Level (ISO 6395:2008)
113.00 dB(A)
113.00 dB(A)
Operator Sound Pressure Level (ISO 6396:2008)*
72.00 dB(A)
72.00 dB(A)
Machine Sound Power Level (ISO 6395:2008)*
110.00 dB(A)
110.00 dB(A)
Note (3)
The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (4)
Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
Features

OPERATOR COMFORT AND CONTROL

TOP-TIER SERVICE AND SUPPORT

EFFICIENCY AND PRODUCTIVITY

PRODUCTIVITY WITH TECHNOLOGY

LONG-TERM VALUE AND DURABILITY

WHEEL TIPS BUILT TO PERFORM

Standard Equipment
  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • POWERTRAIN
    • Single Clutch Speed Shifting (SCSS)
    • Electronic Clutch Pressure Control (ECPC)
    • Air-to-air aftercooler
    • Brakes, full hydraulic, enclosed, wet multiple disc service brakes
    • Cat Clean Emission Module (U.S. EPA Tier 4 Final/ EU Stage V only)
    • Muffler (under hood) (U.S. EPA Tier 3/EU Stage IIIA equivalent)
    • Electro-hydraulic parking brake
    • Engine, Cat C15 configured for two emissions options: Tier 4 Final/Stage V, or emitting equivalent to Tier 3/Stage IIIA
    • Fuel priming pump (electric)
    • Fuel-to-air cooler
    • Ground level engine shutdown
    • Heat shield, turbo and exhaust manifold
    • Hydraulically driven demand fan
    • Integrated braking system
    • Radiator, Aluminum Modular (AMR)
    • Separated cooling system
    • Starting aid (ether)
    • Throttle lock
    • Torque converter with Lock Up Clutch (LUC)
    • Eco Mode
    • Transmission, planetary, with 2F/2R speed range control
    • Under hood ventilation system
  • ELECTRICAL
    • Alarm, back-up
    • Alternator, 150 amp
    • Batteries, maintenance-free (4 - 1,000 CCA)
    • Electrical system, 24V
    • Light, warning unswitched (LED strobe)
    • Lighting system, halogen (front and rear)
    • Lighting, access stairway
    • Lighting, underhood
    • Starter, electric (heavy duty)
    • Ground level lockable master disconnect switch
    • Auxiliary jump start receptacle
  • OPERATOR ENVIRONMENT
    • Camera, rear vision
    • Air conditioner with roof-mounted condenser
    • Cab, sound-suppressed pressurized
    • Internal four-post rollover protective structure (ROPS/FOPS)
    • Radio ready for entertainment: – Antenna – Speakers – Converter (12V, 10-15 amp)
    • 12V power port for mobile phone or laptop connection
    • Radio, CB ready
    • Coat and hard hat hooks
    • Fingertip shifting controls
    • Flip-up armrest
    • Heater and defroster
    • Implement hydraulic lockout
    • Glass (window) - rubber mounted glass
    • Light, (dome) cab
    • Lunch box and beverage holders
    • Instrumentation, gauges: – Diesel exhaust fluid (DEF) level (U.S. EPA Tier 4 Final/ EU Stage V) – Engine coolant temperature – Fuel level – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
    • Instrumentation, warning indicators: – Action alert system, three categories – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp – Parking brake status
    • Mirror, internal (panoramic)
    • Mirrors, heated, rearview (externally mounted)
    • Premium plus seat containing forced air heating and cooling, 2-way thigh adjustment, power lumbar and back bolster adjustment, ride stiffness adjustment, dynamic end dampening, and leather finish
    • Seat belt with minder, retractable, 76 mm (3 in) wide
    • Steering and Transmission Integrated Control (STIC™) system with lockout
    • Sun visor, front
    • Tinted glass
    • Transmission gear (indicator)
    • Vital Information Management System (VIMS™): – Graphical information display – External data port – Customizable operator profiles
    • Wet-arm wipers/washers (front and rear)
    • Intermittent wipers (front and rear)
    • Precleaner, cab powered
    • Horn group (trumpet)
  • GUARDS
    • Guards, axle (front and rear)
    • Guard, cab window
    • Guard, driveshaft
    • Guards, crankcase and powertrain, hydraulically powered
    • Guard, differential (front and rear)
  • FLUIDS
    • Antifreeze, premixed 50% concentration extended life (–34° C/–29° F)
  • OTHER STANDARD EQUIPMENT
    • Demand fan/swing out (hydraulic reversible)
    • Doors, service access (locking)
    • Ecology drains for engine, radiator, transmission, hydraulic tank
    • Emergency platform exit
    • Engine, crankcase, 500 hour interval with CJ-4 oil
    • Engine idle management features: – Auto idle kickdown – Delayed engine shutdown – Engine idle shutdown
    • Fire suppression ready
    • Fuel tank, 782 L (207 gal)
    • Hitch, drawbar with pin
    • Hoses, Cat XT™
    • Hydraulic, engine, and transmission oil coolers
    • Total hydraulic filtration system
    • Oil sampling valves
    • Oil change system, high speed
    • Steering, load sensing
    • Stairway, left and right rear access
    • Vandalism protection caplocks
    • Venturi stack
    • Fold-down exhaust stack for shipping
  • TECHNOLOGY PRODUCTS
    • Product Link™ – Cellular, Satellite
  • SPECIAL ARRANGEMENTS
    • Engine: – Sound suppression
    • Engine precleaners - single stage
  • BLADES
    • Dozer arrangement (no blade)
  • WHEELS AND CLEANER BARS
    • Striker bars
    • Wheels and tips: wheel arrangements – 7" combination tips
Optional Equipment
  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • OPERATOR ENVIRONMENT
    • Radio, AM/FM/Aux/USB/Bluetooth®
    • Cat Compact SBAS Mapping (available through SITECH only)
    • Cat Compact RTK Mapping (available through SITECH only)
  • GUARDS
    • Guard – rear fan and grill
  • POWERTRAIN
    • Heater, engine coolant, 120V
    • Heater, engine coolant, 240V
  • SPECIAL ARRANGEMENTS
    • Engine precleaners – dual stage
  • MISCELLANEOUS
    • Plate – year of manufacture (Tier 3/Stage IIIA equivalent only)
  • WHEELS AND CLEANER BARS
    • Striker bars with cleaner fingers
  • OTHER STANDARD EQUIPMENT
    • Stairway, swingout (LH & RH)
