Overview

Cat Landfill Compactors are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1978, the 826 has been the industry leader for over 35 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 826K continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Weights

Operating Weight
90207.00 lb
40917.00 kg

Engine

Gross Power
435.00 hp
324.00 kW
Net Power
405.00 hp
302.00 kW
Engine Model
Cat® C15 ACERT™
Bore
5.40 in
137.20 mm
Stroke
6.70 in
171.40 mm
Displacement
927.60 in3
15.20 L
Emissions
Tier 4 Final/Stage IV or Tier 3/Stage IIIA equivalent
High Idle Speed
2300.00 RPM
2300.00 RPM
Low Idle Speed
800.00 RPM
800.00 RPM
Maximum Altitude without Derating (Tier 4 Final/Stage IV)
9298.00 ft
2834.00 m
Maximum Net Torque @ 1,300 rpm
1478.80 lbf-ft
2005.00 N·m
Net Power: Converter Drive - Gross Power
435.00 hp
324.00 kW
Net Power: Converter Drive - Torque Rise
8.50 %
8.50 %
Net Power: Direct Drive - Gross Power
412.00 hp
307.00 kW
Net Power: Direct Drive - Torque Rise
33.00 %
33.00 %
Rated Power (Net ISO 9249)
405.00 hp
302.00 kW
Rated Power (Net SAE J1349)
405.00 hp
302.00 kW

Transmission

Transmission Type
Planetary - Powershift - ECPC
Travel Speeds: Forward - Maximum 1st
3.70 mph
6.00 km/h
Travel Speeds: Forward - Maximum 2nd
6.60 mph
10.60 km/h
Travel Speeds - Forward - Maximum Eco Mode
4.30 mile/h
6.90 km/h
Travel Speeds: Reverse - Maximum 1st
4.30 mph
6.90 km/h
Travel Speeds: Reverse - Maximum 2nd
7.60 mph
12.20 km/h
Travel Speeds - Reverse - Maximum Eco Mode
4.60 mile/h
7.40 km/h

Hydraulic System

Bore
4.70 in
120.00 mm
Lift System
Double Acting Cylinder
Main Relief Pressure
3495.00 psi
24100.00 kPa
Maximum Supply Pressure
3495.00 psi
24100.00 kPa
Pump Flow at 1,950 rpm
30.90 gal/min
117.00 L/min
Stroke
42.10 in
1070.00 mm

Axles

Front
Planetary - Fixed
Oscillation Angle
±5°
Rear
Planetary - Oscillating

Brakes

Parking Brake
Drum and Shoe, Spring Applied, Hydraulic Released

Service Refill Capacities

Fuel Tank
206.60 gal
782.00 L
Cooling System
30.60 gal
116.00 L
Transmission
17.40 gal
66.00 L
Differential - Final Drives - Front
26.40 gal (US)
100.00 l
Differential - Final Drives - Rear
29.10 gal (US)
110.00 l
Diesel Exhaust Fluid Tank (Tier 4 Final/Stage IV)
8.50 gal
32.00 L
Engine Crankcase
9.00 gal
34.00 L
Hydraulic Tank Only
35.40 gal (US)
134.00 l

Operating Specifications

Maximum Operating Weight (Tier 4 Final/Stage IV) – Multiple Blade and Wheel Offerings
90207.00 lb
40917.00 kg

Dimensions (Approximate)

Height to Top of Cab with A/C
14.99 ft
4568.00 mm
Height - Top of Exhaust Pipe
14.56 ft
4439.00 mm
Height to Top of Hood
10.87 ft
3312.00 mm
Ground Clearance - Bumper
3.15 ft
960.00 mm
Hitch to Center Line of Front Axle
6.07 ft
1850.00 mm
Hitch to Centerline of Front Axle
6.07 ft
1850.00 mm
Width over Wheels
12.47 ft
3800.00 mm
Center Line of Rear Axle to Edge of Counterweight - Including Rear Radiator Guard
10.16 ft
3096.00 mm
Centerline of Rear Axle to Edge of Counterweight - No Rear Radiator Guard
9.38 ft
2860.00 mm
Height to ROPS/Canopy
14.02 ft
4274.00 mm
Height to Top of Cab with Strobe
15.63 ft
4765.00 mm
Length with Blade on Ground - (includes rear radiator guard) (straight blade)
28.59 ft
8715.00 mm
Turning Radius - Inside of Wheels
9.18 ft
2797.00 mm
Ground Clearance
2.11 ft
642.00 mm

Cab – Suppression

Operator Sound Pressure Level (ISO 6396)
72.00 dB(A)
72.00 dB(A)
Machine Sound Power Level (ISO 6395)
110.00 dB(A)
110.00 dB(A)

Hydraulic System - Steering

Bore
4.50 in
114.30 mm
Maximum System Flow
170 L/min @ 1,950 rpm (44.9 gal/min @ 1,950 rpm)
Steering Pressure Limited
3481.00 psi
24000.00 kPa
Steering System - Circuit
Double Acting - End Mounted
Steering System - Pump
Piston - Variable Displacement
Stroke
22.70 in
576.00 mm
Vehicle Articulation Angle
86.00 °
86.00 °

Cab – Standard

Operator Sound Pressure Level (ISO 6396)
73.00 dB(A)
73.00 dB(A)
Machine Sound Power Level (ISO 6395)
113.00 dB(A)
113.00 dB(A)

Operating Specifications

Maximum Operating Weight (Tier 3 Final/Stage IIIA equivalent) Multiple Blade and Wheel Offerings
89186.00 lb
40454.00 kg

Wheels and Tips

Attachment - Wheels: 1200 mm (47.25 in) Paddle Tips - Drum Diameter
5.28 ft
1610.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle Tips - Drum Width
3.94 ft
1200.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle Tips - Outside Diameter
6.47 ft
1971.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle Tips - Tips per Wheel
30
Attachment - Wheels: 1200 mm (47.25 in) Paddle Tips - Weight
20540.00 lb
9317.00 kg
Attachment - Wheels: 1200 mm (47.25 in) Paddle Tips - Width over Drums
12.47 ft
3800.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle and Plus Tips - Drum Diameter
5.28 ft
1610.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle and Plus Tips - Drum Width
3.94 ft
1200.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle and Plus Tips - Outside Diameter
6.47 ft
1971.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Paddle and Plus Tips - Tips per Wheel
30
Attachment - Wheels: 1200 mm (47.25 in) Paddle and Plus Tips - Weight
21125.00 lb
9582.00 kg
Attachment - Wheels: 1200 mm (47.25 in) Paddle and Plus Tips - Width over Drums
12.47 ft
3800.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Plus Tips - Drum Diameter
5.28 ft
1610.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Plus Tips - Drum Width
3.94 ft
1200.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Plus Tips - Outside Diameter
6.47 ft
1971.00 mm
Attachment - Wheels: 1200 mm (47.25 in) Plus Tips - Tips per Wheel
30
Attachment - Wheels: 1200 mm (47.25 in) Plus Tips - Weight
22002.00 lb
9980.00 kg
Attachment - Wheels: 1200 mm (47.25 in) Plus Tips - Width over Drums
12.47 ft
3800.00 mm

Engine

Maximum Altitude without Derating (Tier 3/Stage IIIA)
9098.00 ft
2773.00 m
Gross Power
435.00 HP
324.00 kW
Net Power
405.00 HP
302.00 kW
Engine Model
Cat® C15 ACERT™
Bore
5.40 in
137.20 mm
Stroke
6.70 in
171.40 mm
Displacement
927.60 in³
15.20 l
Emissions
Tier 4 Final/Stage IV or Tier 3/Stage IIIA equivalent
High Idle Speed
2300.00 r/min
2300.00 r/min
Low Idle Speed
800.00 r/min
800.00 r/min
Maximum Altitude - Without Derating (Tier 4 Final/Stage IV)
9298.00 ft
2834.00 m
Maximum Net Torque - 1,300 rpm
1478.80 ft·lbf
2005.00 N·m
Net Power - Converter Drive - Gross Power
435.00 HP
324.00 kW
Net Power - Converter Drive - Torque Rise
8.50 %
8.50 %
Net Power - Direct Drive - Gross Power
412.00 HP
307.00 kW
Net Power - Direct Drive - Torque Rise
33.00 %
33.00 %
Rated Power (Net ISO 9249)
405.00 HP
302.00 kW
Rated Power (Net SAE J1349)
405.00 HP
302.00 kW

Transmission

Transmission Type
Planetary - Powershift - ECPC
Travel Speed - Forward - Maximum 1st
3.70 mile/h
6.00 km/h
Travel Speed - Forward - Maximum 2nd
6.60 mile/h
10.60 km/h
Travel Speed - Reverse - Maximum 1st
4.30 mile/h
6.90 km/h
Travel Speed - Reverse - Maximum 2nd
7.60 mile/h
12.20 km/h

Hydraulic System

Bore
4.70 in
120.00 mm
Lift System
Double Acting Cylinder
Pump Flow at 1,950 rpm
30.90 gal/min
117.00 l/min
Stroke
42.10 in
1070.00 mm

Axles

Front
Planetary - Fixed
Rear
Planetary - Oscillating

Brakes

Parking Brake
Drum and Shoe, Spring Applied, Hydraulic Released

Service Refill Capacities

Fuel Tank
206.60 gal (US)
782.00 l
Cooling System
30.60 gal (US)
116.00 l
Transmission
17.40 gal (US)
66.00 l
Diesel Exhaust Fluid Tank (Tier 4 Final/Stage IV)
8.50 gal (US)
32.00 l
Engine Crankcase
9.00 gal (US)
34.00 l

Weights

Operating Weight
90207.00 lb
40917.00 kg

Cab - Standard

Machine Sound Power Level (ISO 6395)
113.00 dB(A)
113.00 dB(A)
Operator Sound Pressure Level - ISO 6396
73.00 dB(A)
73.00 dB(A)

Cab - Suppression

Machine Sound Power Level (ISO 6395)
110.00 dB(A)
110.00 dB(A)
Operator Sound Pressure Level - ISO 6396
72.00 dB(A)
72.00 dB(A)

Operating Specifications

Maximum Operating Weight (Tier 4 Final/Stage IV) - Multiple Blade and Wheel Offerings
90207.00 lb
40917.00 kg
Maximum Operating Weight (Tier 3 Final/Stage IIIA equivalent) Multiple Blade and Wheel Offerings
89186.00 lb
40454.00 kg

Dimensions (Approximate)

Height - Top of Cab with A/C
14.99 ft
4568.00 mm
Height - Top of Hood
10.87 ft
3312.00 mm
Wheel Base
12.14 ft
3700.00 mm
Width - Over Wheels
12.47 ft
3800.00 mm
Centerline of Rear Axle to Edge of Counterweight - Including Rear Radiator Guard
10.16 ft
3096.00 mm
Height - ROPS/Canopy
14.02 ft
4274.00 mm
Height - Top of Cab with Strobe
15.63 ft
4765.00 mm
Length - With Blade on Ground - Straight Blade - Including Rear Radiator Guard
28.59 ft
8715.00 mm
Turning Radius - Inside of Wheels
9.18 ft
2797.00 mm
Ground Clearance
2.11 ft
642.00 mm

Engine

Maximum Altitude - Without Derating (Tier 3/Stage IIIA)
9098.00 ft
2773.00 m
Features

POWERFUL EFFICIENCY

LONG TERM VALUE AND DURABILITY

PERFORMANCE WITH LESS FUEL

WHEEL TIPS BUILT TO PERFORM

OPERATOR COMFORT AND CONTROL

PRODUCTIVITY WITH TECHNOLOGY

BUILT-IN SAFETY FEATURES

REDUCE ENVIRONMENTAL IMPACT

TOP-TIER SERVICE AND SUPPORT

Sales Features

Efficiency and Productivity

Delivering the efficiency and productivity you demand through integrated machine systems.

Structures

Purpose-built from the ground up for the toughest conditions.

Power Train

Operate more efficiently with improved power and control.

Operator Station

Best-in-class operator comfort and ergonomics.

Integrated Technologies

Monitor, manage, and enhance your job site operations.

Serviceability

Enabling high uptime by reducing your service time.

Customer Support

Your Cat dealers know how to keep your machines productive.

Safety

Making your safety our priority.

Sustainability

Stewards of the environment.

Waste Protection

Maximize uptime, long life - it’s what you expect from your bottom line.

Wheels and Tips

More options to fit your operation.

Operating Costs

Save time and money by working smart.
Standard Equipment
  • POWER TRAIN
    • Single Clutch Speed Shifting (SCSS)
    • Electronic Clutch Pressure Control (ECPC)
    • Air to air aftercooler
    • Brakes, full hydraulic, enclosed, wet multiple disc service brakes
    • Cat clean emission module (insulated) (Tier 4 Final/Stage IV)
    • Muffler (under hood) (U.S. EPA Tier 3/EU Stage IIIA equivalent)
    • Electro-hydraulic parking brake
    • Engine, Cat C15 with ACERT Technology: – Tier 4 Final/Stage IV – Tier 3/Stage IIIA equivalent
    • Fuel priming pump (electric)
    • Fuel to air cooler
    • Ground level engine shutoff
    • Heat shield, turbo and exhaust manifold
    • Hydraulically driven demand fan
    • Integrated braking system
    • Radiator, Aluminum Modular (AMR)
    • Separated cooling system
    • Starting aid (ether) automatic
    • Throttle lock
    • Torque converter with Lock Up Clutch (LUC)
    • Eco Mode
    • Transmission, planetary, with 2F/2R speed range control
    • Under hood ventilation system
  • ELECTRICAL
    • Alarm, back-up
    • Alternator, 150 amp
    • Batteries, maintenance-free (4 - 1,000 CCA)
    • Electrical system, 24V
    • Light, warning unswitched (LED strobe)
    • Lighting system, halogen (front and rear)
    • Lighting, access stairway
    • Lighting, underhood
    • Starter, electric (heavy duty)
    • Ground level lockable master disconnect switch
    • Starting receptacle for emergency start
  • OPERATOR ENVIRONMENT
    • Air conditioner with roof mounted condenser
    • Cab, sound-suppressed pressurized
    • Internal four-post rollover protective structure (ROPS/FOPS)
    • Radio ready for entertainment: – Antenna – Speakers – Converter (12V, 10-15 amp)
    • 12V power port for mobile phone or laptop connection
    • Radio, CB ready
    • Coat and hard hat hooks
    • Hydraulic controls (seat mounted)
    • Finger tip shifting controls
    • Flip-up armrest
    • Heater and defroster
    • Implement hydraulic lockout
    • Laminated glass
    • Light, (dome) cab
    • Lunch box and beverage holders
    • Instrumentation, gauges: – DEF fluid level (Tier 4 Final/Stage IV) – Engine coolant temperature – Fuel level – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
    • Instrumentation, warning indicators: – Action alert system, three categories – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp – Parking brake status
    • Mirror, internal (panoramic)
    • Mirrors, rearview (externally mounted)
    • Seat, Cat Comfort (cloth) air suspension
    • Seat belt with minder, retractable, 76 mm (3 in) wide
    • STIC control system with lockout
    • Sun visor, front
    • Tinted glass
    • Transmission gear (indicator)
    • Vital Information Management System (VIMS): – Graphical information display – External data port – Customizable operator profiles
    • AccuGrade mapping (ready)
    • Wet-arm wipers/washers (front and rear)
    • Intermittent wipers (front and rear)
  • GUARDS
    • Guards, axle (front and rear)
    • Guard, cab window
    • Guard, driveshaft
    • Guards, crankcase and power train, hydraulically powered
    • Striker bars
  • FLUIDS
    • Antifreeze, premixed 50% concentration extended life (–34° C/–29° F)
  • OTHER STANDARD EQUIPMENT
    • Demand fan/swing out (hydraulic reversible)
    • Doors, service access (locking)
    • Ecology drains for engine, radiator, transmission, hydraulic tank
    • Emergency platform egress
    • Engine, crankcase, 500 hour interval with CJ-4 oil
    • Engine idle management features: – Auto idle kickdown – Delayed engine shutdown – Engine idle shutdown
    • Fire suppression ready
    • Fuel tank, 782 L (207 gal)
    • Hitch, drawbar with pin
    • Hoses, Cat XT
    • Hydraulic, engine, and transmission oil coolers
    • Total hydraulic filtration system
    • Oil sampling valves
    • Oil change system, high speed
    • Steering, load sensing
    • Stairway, left and right rear access
    • Vandalism protection caplocks
    • Venturi stack
    • Fold down exhaust stack for shipping
  • STANDARD ATTACHMENTS
    • VIMS/Product Link: – GSM, satellite
    • Engine: – Sound suppression
    • Precleaner – cab: – Standard or powered
    • Window: – Standard bonded or rubber-mounted glass
    • Horn: – Standard or trumpet
    • Stairs: – Fixed or swingout
    • Striker bars or striker bars with cleaner fingers
    • Blades: – Straight, Semi-U, U
    • Wheels: – Various tip and wheel arrangements (Paddle and Plus [combination], Paddle, Plus, Chopper [U.S. EPA Tier 3/EU Stage IIIA equivalent], Omission)
    • Precleaner – engine: – Turbine or dual stage
Optional Equipment
  • ELECTRICAL
    • Camera, rear vision
  • OPERATOR ENVIRONMENT
    • Radio (includes AM/FM, MP3, Bluetooth, hands free microphone)
  • GUARDS
    • Guard – rear
  • STARTING AIDS
    • Heater, engine coolant, 120V
    • Heater, engine coolant, 240V
  • MISCELLANEOUS
    • Film (ANSI) (HRC)
    • EU certification (HRC)
    • Plate – year of manufacture (LRC)
