836 Landfill Compactor
836 Landfill Compactor
836 Landfill Compactor
836 Landfill Compactor
836 Landfill Compactor
836 Landfill Compactor
US
Metric

Overview

Cat Landfill Compactors are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1993, the 836 has been the industry leader for over 30 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 836 continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Engine

Gross Power
562.00 HP
419.00 kW
Net Power
496.00 HP
370.00 kW
Engine Model
C18 Cat®
Bore
5.71 in
145.00 mm
Stroke
7.20 in
183.00 mm
Displacement
1104.50 in³
18.10 l
Net Power - SAE J1349 - Direct Drive - Torque Rise
52.00 %
52.00 %
Net Power - SAE J1349 - Direct Drive - Gross Power
496.00 HP
370.00 kW
Rated Power (Lab)
555.00 HP
414.00 kW
Rated Power (Net ISO 14396)
553.00 HP
412.00 kW
High Idle Speed
2120.00 r/min
2120.00 r/min
Maximum Altitude - Without Derating
7500.00 ft
2286.00 m
Low Idle Speed
750.00 r/min
750.00 r/min
Emissions
U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V and Japan 2014 or Brazil MAR-1, equivalent to China Nonroad Stage III/U.S. EPA Tier 3/EU Stage IIIA
Net Power - SAE J1349 - Converter Drive - Torque Rise
52.00 %
52.00 %
Gross - SAE J1349
562.00 HP
419.00 kW
Net Power - SAE J1349 - Converter Drive - Gross Power
496.00 HP
370.00 kW
Maximum Gross Torque - 1,300 rpm
2275.00 ft·lbf
3085.00 N·m
Torque Rise
52.00 %
52.00 %

Operating Specifications - Tier 4 Final/EU Stage V

Operating Weight
124063.00 lb
56275.00 g

Transmission

Transmission Type
Planetary - Powershift - ECPC
Direct Drive - Forward 1
4.30 mile/h
7.00 km/h
Direct Drive - Forward 2
7.80 mile/h
12.60 km/h
Direct Drive - Reverse 1
4.60 mile/h
7.40 km/h
Direct Drive - Reverse 2
8.20 mile/h
13.20 km/h

Hydraulic System

Bore (1)
5.00 in
127.00 mm
Stroke (1)
29.10 in
740.00 mm
Maximum Supply Pressure
4640.00 psi
32000.00 kPa
Main Relief Pressure
3495.00 psi
24100.00 kPa
Stroke (2)
40.20 in
1021.00 mm
Bore (2)
5.50 in
137.90 mm
Lift System
Double Acting Cylinder
Hydraulic System
Flow Sharing Implement
Vehicle Articulation Angle
86°
Steering System
Double Acting – End Mounted
Pump Flow at 2,006 rpm
66.00 gal/min
250.00 l/min

Hydraulic System - Steering

Steering System - Circuit
Flow Sharing Implement; Pilot, load sensing
Steering System - Pump
Piston – Variable Displacement
Relief Valve Setting - Steering
3495.00 lb/in²
24100.00 kPa
Total Steering Angle
86
Steering Cycle Times - High Idle
3.90 s
3.90 s
Steering Cycle Times - Low Idle
6.40 s
6.40 s

Braking System

Parking Brake
Spring Applied, Hydraulic Released

Service Refill Capacities

Fuel Tank
209.00 gal (US)
793.00 l
Diesel Exhaust Fluid Tank*
9.00 gal (US)
32.80 l
Cooling Systems - Tier 4 Final/EU Stage V
40.00 gal (US)
151.50 l
Cooling Systems - Brazil MAR-1 and China Nonroad Stage III, equivalent to Tier 3/EU Stage IIIA
37.20 gal (US)
141.10 l
Engine Crankcase
16.00 gal (US)
60.00 l
Transmission
21.90 gal (US)
83.00 l
Differential - Final Drives - Front
49.00 gal (US)
186.00 l
Differential - Final Drives - Rear
50.00 gal (US)
190.00 l
Hydraulic System - Implement/Steering
46.20 gal (US)
175.00 l
Hydraulic Tank Only
27.20 gal (US)
103.00 l

Axles

Front
Planetary – Fixed
Rear
Planetary – Oscillating
Oscillation Angle
±6°

Service Brake

Brakes
Multi Disc Wet (Enclosed) 2 WHL

Parking Brake

Brakes
Spring Applied, Hydraulic Released

Sound Performance - Tier 4 Final/EU Stage V - Standard

Operator Sound Level (ISO 6396)
72.00 dB(A)
72.00 dB(A)
Machine Sound Level (ISO 6395)
111.00 dB(A)
111.00 dB(A)

Sound Performance - Tier 4 Final/EU Stage V - Suppression

Machine Sound Level (ISO 6395)
109.00 dB(A)
109.00 dB(A)

Sound Performance - Brazil Mar-1 and China Nonroad Stage III, Equivalent to Tier 3/EU Stage IIIA - Suppression

Operator Sound Level (ISO 6396)
72.00 dB(A)
72.00 dB(A)

Sound Performance - Tier 4 Final/EU Stage V - Suppression

Operator Sound Level (ISO 6396)
72.00 dB(A)
72.00 dB(A)

Weights

Operating Weight
123319.00 lb
55927.00 kg

Cab

Interior Sound Level - Standard
72.00 dB(A)
72.00 dB(A)
Exterior Sound Level - Suppression
109.00 dB(A)
109.00 dB(A)
Interior Sound Level - Suppression
71.00 dB(A)
71.00 dB(A)
Exterior Sound Level - Standard
111.00 dB(A)
111.00 dB(A)

Operating Specifications

Maximum Operating Weight (Tier 3/Stage IIIA equivalent) - Multiple Blade and Wheel Offerings
125622.00 lb
56982.00 kg
Maximum Operating Weight (Tier 4 Final/Stage IV/Korea Tier 4 Final) - Multiple Blade and Wheel Offerings
123319.00 lb
57318.00 kg

Dimensions (Approximate)

Height - Top of Cab with A/C
15.27 ft
4655.00 mm
Height - Top of Exhaust Pipe
15.10 ft
4606.00 mm
Height - Top of Hood
11.30 ft
3430.00 mm
Ground Clearance - Bumper
3.38 ft
1029.00 mm
Centerline of Rear Axle to Edge of Counterweight
10.46 ft
3187.00 mm
Hitch to Centerline of Front Axle
7.50 ft
2275.00 mm
Wheel Base
14.90 ft
4550.00 mm
Width - Over Wheels
14.04 ft
4280.00 mm
Height - Top of Cab with Strobe
15.90 ft
4845.00 mm
Length - With Blade on Ground - Straight Blade
33.41 ft
10182.00 mm
Height - ROPS/Canopy
14.06 ft
4284.00 mm
Turning Radius - Inside of Wheels
11.93 ft
3635.00 mm
Ground Clearance
2.07 ft
632.00 mm

Wheels and Tips

Diameter - With Tips
7.00 ft
2125.00 mm
Tips per Wheel
40
Drum Diameter
5.81 ft
1770.00 mm
Drum Width
4.59 ft
1400.00 mm

Operating Specifications

Operating Weight - With Full Tank Capacities and U-Blade (Tier 4 Final/Stage IV/Korea Tier 4 Final)
123319.00 lb
55927.00 kg
Operating Weight - With Full Tank Capacities and U-Blade (Tier 3/Stage IIIA Equivalent)
122615.00 lb
55617.00 kg

Engine - Tier 4 Final/EU Stage V

Gross Power (SAE J1995:2014)
562.00 HP
419.00 kW
Net Power (SAE J1349:2011)
496.00 HP
370.00 kW
Net Power (ISO 9249:2007)
502.00 HP
374.00 kW
Engine Model
C18
Emissions
U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V and Japan 2014
Rated Speed
1900.00 r/min
1900.00 r/min
Torque Rise
52
Bore
5.71 in
145.00 mm
Stroke
7.20 in
183.00 mm
Displacement
1104.50 in³
18.10 l
High Idle Speed
2120.00 r/min
2120.00 r/min
Low Idle Speed
750.00 r/min
750.00 r/min
Maximum Altitude without Derating
7500.00 ft
2286.00 m
Note
*Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator.

Operating Specifications

Maximum Operating Weight (Tier 3/Stage IIIA equivalent)
125622.00 lb
56982.00 kg

Service Refill Capacities

Cooling System - Tier 3/Stage IIIA Equivalent
37.20 gal (US)
141.10 l

Braking System

Service Brakes
Multi Disc Wet (Enclosed) 2 WHL

Dimensions (Approximate)

Height to Top of Beacon
15.20 ft
4634.00 mm
Height to Top of Air Conditioning Condenser
15.20 ft
4626.00 mm
Height - Cab Roof
14.10 ft
4285.00 mm
Ground Clearance to Hitch
2.10 ft
639.00 mm
Ground Clearance to Bottom of Bumper
3.20 ft
965.00 mm
Centerline of Rear Axle to Rear Compactor Guard
11.30 ft
3454.00 mm
Width over Front Striker Bars
12.90 ft
3930.00 mm
Width over Rear Striker Bars
12.90 ft
3933.00 mm
Width over Platform
10.50 ft
3196.00 mm
Width over Drums
14.00 ft
4280.00 mm

Straight Blade

Capacity
25.90 yd³
19.30 m³
Height
7.30 ft
2239.00 mm
Height of Cutting Edge
7.30 ft
1125.00 mm

Semi U-Blade

Capacity
29.30 yd³
22.40 m³
Height
7.30 ft
2239.00 mm

U-Blade

Capacity
33.60 yd³
25.50 m³
Height
7.40 ft
2255.00 mm
Features

OPERATOR COMFORT AND CONTROL

BECAUSE UPTIME COUNTS

POWERFUL EFFICIENCY

PRODUCTIVITY WITH TECHNOLOGY

LONG TERM VALUE AND DURABILITY

WHEEL TIPS BUILT TO PERFORM

Standard Equipment
  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • POWER TRAIN
    • Advanced Productivity Electronic Control Shifting (APECS)
    • Air to air aftercooler
    • Brakes, fully hydraulic, enclosed, wet multiple disc brakes
    • Cat Clean Emission Module, insulated (Tier 4 Final/Stage V/Korea Stage V and Japan 2014)
    • Electro hydraulic parking brake
    • Engine, Cat C18: – Tier 4 Final/Stage V/Korea Stage V and Japan 2014 – Tier 3/Stage IIIA equivalent
    • Fuel priming pump, electric
    • Fuel to air cooler
    • Ground level engine shutoff
    • Guard (3 piece) transmission
    • Heat shield, turbo and exhaust manifold
    • Hydraulically driven demand fan
    • Integrated braking
    • Radiator, Aluminum Modular Radiator (AMR)
    • Separated cooling system
    • Starting aid (ether) automatic
    • Throttle lock
    • Torque converter with lockup clutch (LUC)
    • Turbine precleaner, engine air intake
    • Transmission, planetary, with 2F/2R speed range control
    • Underhood ventilation system
  • ELECTRICAL
    • Alarm, back-up
    • Alternator, 150 amp
    • Batteries, maintenance-free (4-1,000 CCA)
    • Converter, 10-15 amp, 24V to 12V
    • Lighting system, halogen (front and rear)
    • Lighting, access stairway
    • Starter, electric (heavy duty)
    • Starter lockout (ground level)
    • Starting receptacle for emergency start
    • Transmission lockout (ground level)
  • OPERATOR ENVIRONMENT
    • Air conditioner w/roof-mounted condenser
    • Cab, sound-suppressed and pressurized
    • Internal four-post rollover protective structure (ROPS/FOPS)
    • Radio ready for (entertainment) includes antenna, speakers and converter (12V, 10-15 amp) 12V power port for mobile phone or laptop connection
    • Camera, rear vision
    • Coat and hard hat hooks
    • Flip-up armrest
    • Heater and defroster
    • Horn, electric
    • Hydraulic controls (floor mounted)
    • Implement hydraulic lockout
    • Laminated glass
    • Light, (dome) cab
    • Lunchbox and beverage holders
    • Instrumentation, Gauges: – DEF fluid level (Tier 4 Final/Stage IV) – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
    • Instrumentation, Warning Indicators: – Action alert system, three category – Axle/brake oil temp, front – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp
    • Mirrors, rearview (externally mounted)
    • Parking brake status
    • Radio, CB (ready)
    • Seat, Cat Comfort, (cloth) air suspension
    • Seat belt, retractable, 76 mm (3") wide
    • STIC Control System with steering lock
    • Sun visor, front
    • Glass (window) - rubber mounted glass
    • Transmission gear (indicator)
    • Vital Information Management System (VIMS) with graphical information display: external data port, customizable operator profiles
    • Wet-arm wipers/washers (front and rear)
    • Intermittent wipers (front and rear)
  • WHEELS
    • Wheels, paddle, plus, combination, and diamond wheel configurations
  • GUARDS
    • Guards, axle (front and rear)
    • Guards, cab window
    • Guards, crankcase and power train, hydraulically powered
    • Guards, rear fan and grill
  • BLADES
    • Bulldozer arrangement is included in the standard equipment. Bulldozer blades are optional.
  • FLUIDS
    • Antifreeze, premixed 50% concentration of extended life coolant with freeze protection to –34° C (–29° F)
  • OTHER STANDARD EQUIPMENT
    • Auto Blade Positioner (ABP)
    • Demand fan/swing out (hydraulic reversible)
    • Doors, service access locking
    • Ecology drains for engine, radiator, hydraulic tank
    • Electronic clutch pressure control and remote mounted pressure taps
    • Emergency platform egress
    • Engine, crankcase, 500 hour interval with CJ-4 oil
    • Fuel tank, 793 L (210 gal)
    • Hitch, drawbar with pin
    • Hoses, Cat XT™
    • Hydraulic oil cooler
    • Hydraulic, steering and brake filtration/screening system
    • Oil sampling valves
    • Product Link™ - Cellular
    • Stairways, fixed-L/R (rear access)
    • Steering, load sensing
    • Vandalism protection caplocks
    • Venturi stack
Optional Equipment
  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • Various blades:
    • Straight blade
    • U-blade
    • Semi U-blade
  • Various tip and wheel arrangements:
    • Paddle
    • Plus
    • Diamond
