Overview

Cat Landfill Compactors are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1993, the 836 has been the industry leader for over 20 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 836K continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Weights

Operating Weight
123319.00 lb
55927.00 kg

Engine

Gross Power
562.00 hp
419.00 kW
Net Power
496.00 hp
370.00 kW
Engine Model
Cat® C18 ACERT™
Bore
5.71 in
145.00 mm
Stroke
7.20 in
183.00 mm
Displacement
1104.50 in3
18.10 L
Emissions
Tier 4 Final/Stage IV/Korea Tier 4 Final or Tier 3/Stage IIIA equivalent
Gross - SAE J1349
562.00 HP
419.00 kW
High Idle Speed
2120.00 rpm
2120.00 rpm
Low Idle Speed
750.00 rpm
750.00 rpm
Maximum Altitude without Derating
7500.00 ft
2286.00 m
Maximum Gross Torque - 1,300 rpm
2275.00 ft·lbf
3085.00 N·m
Net Power - SAE J1349 - Converter Drive - Gross Power
496.00 HP
370.00 kW
Net Power - SAE J1349 - Converter Drive - Torque Rise
52.00 %
52.00 %
Net Power - SAE J1349 - Direct Drive - Gross Power
496.00 HP
370.00 kW
Net Power - SAE J1349 - Direct Drive - Torque Rise
52.00 %
52.00 %
Rated Power (Lab)
555.00 HP
414.00 kW
Rated Power (Net ISO 14396)
553.00 HP
412.00 kW

Transmission

Transmission Type
Planetary – Powershift – ECPC
Travel Speed - Forward - Converter 1st
3.90 mile/h
6.20 km/h
Travel Speed - Forward - Converter 2nd
6.80 mile/h
10.90 km/h
Travel Speed - Forward - Lockup 1st
4.00 mile/h
6.50 km/h
Travel Speed - Forward - Lockup 2nd
7.30 mile/h
11.70 km/h
Travel Speed - Reverse - Converter 1st
4.00 mile/h
6.50 km/h
Travel Speed - Reverse - Converter 2nd
6.50 mile/h
10.40 km/h
Travel Speed - Reverse - Lockup 1st
4.30 mile/h
6.90 km/h
Travel Speed - Reverse - Lockup 2nd
7.60 mile/h
12.30 km/h

Hydraulic System

Bore (1)
5.00 in
127.00 mm
Bore (2)
5.50 in
137.90 mm
Hydraulic System
Flow Sharing Implement
Lift System
Double Acting Cylinder
Main Relief Pressure
3495.00 psi
24100.00 kPa
Maximum Supply Pressure
4640.00 psi
32000.00 kPa
Pump Flow at 2,006 rpm
66.00 gal/min
250.00 l/min
Steering System
Double Acting – End Mounted
Stroke
29.10 in
740.00 mm
Stroke
40.20 in
1021.00 mm
Vehicle Articulation Angle
86°

Axles

Front
Planetary – Fixed
Oscillation Angle
13°
Rear
Planetary – Oscillating

Brakes

Control System
Full Hydraulic Split Circuit
Parking Brake
Spring Applied, Hydraulic Released

Service Refill Capacities

Fuel Tank
209.00 gal
793.00 L
Cooling System
28.00 gal
107.00 L
Crankcase
16.00 gal
60.00 L
Transmission
32.00 gal
120.00 L
Differential - Final Drives - Front
49.00 gal (US)
186.00 l
Differential - Final Drives - Rear
50.00 gal (US)
190.00 l
Diesel Engine Fluid Tank (Tier 4 Final/Stage IV/Korea Tier 4 Final)
9.00 gal (US)
32.80 l
Hydraulic System - Tank Only
63.00 gal (US)
240.00 l

Cab

Exterior Sound Level - Standard
111.00 dB(A)
111.00 dB(A)
Exterior Sound Level - Suppression
109.00 dB(A)
109.00 dB(A)
Interior Sound Level - Standard
72.00 dB(A)
72.00 dB(A)
Interior Sound Level - Suppression
71.00 dB(A)
71.00 dB(A)

Operating Specifications

Maximum Operating Weight (Tier 4 Final/Stage IV/Korea Tier 4 Final) – Multiple Blade and Wheel Offerings
123319.00 lb
55927.00 kg
Maximum Operating Weight (Tier 3/Stage IIIA equivalent) - Multiple Blade and Wheel Offerings
122615.00 lb
55617.00 kg

Dimensions (Approximate)

Height to Top of Cab with A/C
15.27 ft
4655.00 mm
Height - Top of Exhaust Pipe
15.12 ft
4608.00 mm
Height to Top of Hood
11.22 ft
3421.00 mm
Ground Clearance - Bumper
3.38 ft
1029.00 mm
Centerline of Rear Axle to Edge of Counterweight
10.46 ft
3187.00 mm
Hitch to Center Line of Front Axle
7.46 ft
2275.00 mm
Hitch to Centerline of Front Axle
7.46 ft
2275.00 mm
Width over Wheels
14.04 ft
4280.00 mm
Height to ROPS/Canopy
14.06 ft
4284.00 mm
Height to Top of Cab with Strobe
15.90 ft
4845.00 mm
Length - With Blade on Ground - Straight Blade
33.41 ft
10182.00 mm
Turning Radius – Inside of Wheels
11.93 ft
3635.00 mm
Ground Clearance
2.07 ft
632.00 mm

Wheels and Tips

Diameter - With Tips
7.00 ft
2125.00 mm
Drum Diameter
5.81 ft
1770.00 mm
Drum Width
4.59 ft
1400.00 mm
Tips per Wheel
40

Hydraulic System - Steering

Maximum Flow at × rpm
52 L/min @ 2,006 rpm
Steering Pressure Limited
3495.00 psi
24100.00 kPa
Steering System - Circuit
Steering Double Acting – End Mounted
Steering System - Pump
Piston – Variable Displacement
Total Steering Angle
86 degrees

Operating Specifications

Operating Weight - With Full Tank Capacities and U-Blade (Tier 4 Final/Stage IV/Korea Tier 4 Final)
123319.00 lb
55927.00 kg
Operating Weight - With Full Tank Capacities and U-Blade (Tier 3/Stage IIIA Equivalent)
122615.00 lb
55617.00 kg

Engine

Gross Power
562.00 HP
419.00 kW
Net Power
496.00 HP
370.00 kW
Engine Model
Cat® C18 ACERT™
Bore
5.71 in
145.00 mm
Stroke
7.20 in
183.00 mm
Displacement
1104.50 in³
18.10 l
Emissions
Tier 4 Final/Stage IV/Korea Tier 4 Final or Tier 3/Stage IIIA equivalent
High Idle Speed
2120.00 r/min
2120.00 r/min
Low Idle Speed
750.00 r/min
750.00 r/min
Maximum Altitude - Without Derating
7500.00 ft
2286.00 m

Transmission

Transmission Type
Planetary – Powershift – ECPC

Hydraulic System

Lift System
Double Acting Cylinder
Stroke (1)
29.10 in
740.00 mm
Stroke (2)
40.20 in
1021.00 mm

Axles

Front
Planetary – Fixed
Oscillation Angle
13°
Rear
Planetary – Oscillating

Brakes

Parking Brake
Spring Applied, Hydraulic Released

Service Refill Capacities

Fuel Tank
209.00 gal (US)
793.00 l
Cooling System
28.00 gal (US)
107.00 l
Crankcase
16.00 gal (US)
60.00 l
Transmission
32.00 gal (US)
120.00 l

Weights

Operating Weight
123319.00 lb
55927.00 kg

Operating Specifications

Maximum Operating Weight (Tier 4 Final/Stage IV/Korea Tier 4 Final) - Multiple Blade and Wheel Offerings
123319.00 lb
55927.00 kg

Dimensions (Approximate)

Height - Top of Cab with A/C
15.27 ft
4655.00 mm
Height - Top of Hood
11.22 ft
3421.00 mm
Wheel Base
14.93 ft
4550.00 mm
Width - Over Wheels
14.04 ft
4280.00 mm
Height - ROPS/Canopy
14.06 ft
4284.00 mm
Height - Top of Cab with Strobe
15.90 ft
4845.00 mm
Turning Radius - Inside of Wheels
11.93 ft
3635.00 mm
Ground Clearance
2.07 ft
632.00 mm
Features

POWERFUL EFFICIENCY

LONG TERM VALUE AND DURABILITY

PERFORMANCE WITH LESS FUEL

WHEEL TIPS BUILT TO PERFORM

OPERATOR COMFORT AND CONTROL

PRODUCTIVITY WITH TECHNOLOGY

BUILT-IN SAFETY FEATURES

REDUCE ENVIRONMENTAL IMPACT

TOP-TIER SERVICE AND SUPPORT

Sales Features

Efficiency and Productivity

Delivering efficiency and productivity you demand through integrated machine systems.

Structures

Best built for the toughest conditions.

Power Train

Operate more efficiently with improved power and control.

Operator Station

Best-in-class operator comfort and ergonomics.

Integrated Technologies

Monitor, manage, and enhance your job site operations.

Serviceability

Enabling high uptime by reducing your service time.

Customer Support

Your Cat dealers know how to keep your machines productive.

Safety

Making your safety our priority.

Sustainability

Stewards of the environment.

Waste Protection

Maximize uptime, long life – it’s what you expect from your bottom line.

Wheels and Tips

More options to fit your operation.

Operating Costs

Save time and money by working smart.
Standard Equipment
  • POWER TRAIN
    • Advanced Productivity Electronic Control Shifting (APECS)
    • Air to air aftercooler
    • Brakes, fully hydraulic, enclosed, wet multiple disc brakes
    • Cat Clean Emission Module, insulated (Tier 4 Final/Stage IV/Korea Tier 4 Final)
    • Electro hydraulic parking brake
    • Engine, Cat C18 with ACERT Technology: – Tier 4 Final/Stage IV/Korea Tier 4 Final – Tier 3/Stage IIIA equivalent
    • Fuel priming pump, electric
    • Fuel to air cooler
    • Ground level engine shutoff
    • Guard (3 piece) transmission
    • Heat shield, turbo and exhaust manifold
    • Hydraulically driven demand fan
    • Integrated braking
    • Radiator, Aluminum Modular Radiator (AMR)
    • Separated cooling system
    • Starting aid (ether) automatic
    • Throttle lock
    • Torque converter with lockup clutch (LUC)
    • Turbine precleaner, engine air intake
    • Transmission, planetary, with 2F/2R speed range control
    • Underhood ventilation system
  • ELECTRICAL
    • Alarm, back-up
    • Alternator, 150 amp
    • Batteries, maintenance-free (4-1,000 CCA)
    • Converter, 10-15 amp, 24V to 12V
    • Lighting system, halogen (front and rear)
    • Lighting, access stairway
    • Starter, electric (heavy duty)
    • Starter lockout (ground level)
    • Starting receptacle for emergency start
    • Transmission lockout (ground level)
  • OPERATOR ENVIRONMENT
    • Air conditioner
    • Cab, sound-suppressed and pressurized
    • Internal four-post rollover protective structure (ROPS/FOPS)
    • Radio ready for (entertainment) includes antenna, speakers and converter (12V, 10-15 amp) 12V power port for mobile phone or laptop connection
    • Camera, rear vision
    • Coat and hard hat hooks
    • Flip-up armrest
    • Heater and defroster
    • Horn, electric
    • Hydraulic controls (floor mounted)
    • Implement hydraulic lockout
    • Laminated glass
    • Light, (dome) cab
    • Lunchbox and beverage holders
    • Instrumentation, Gauges: – DEF fluid level (Tier 4 Final/Stage IV) – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
    • Instrumentation, Warning Indicators: – Action alert system, three category – Axle/brake oil temp, front – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp
    • Mirrors, rearview (externally mounted)
    • Parking brake status
    • Radio, CB (ready)
    • Seat, Cat Comfort, (cloth) air suspension
    • Seat belt, retractable, 76 mm (3") wide
    • STIC Control System with steering lock
    • Sun visor, front
    • Tinted glass
    • Transmission gear (indicator)
    • Vital Information Management System (VIMS) with graphical information display: external data port, customizable operator profiles
    • Wet-arm wipers/washers (front and rear)
    • Intermittent wipers (front and rear)
  • WHEELS
    • Wheels, paddle, plus, combination, and diamond wheel configurations
  • GUARDS
    • Guards, axle (front and rear)
    • Guards, cab window
    • Guards, crankcase and power train, hydraulically powered
    • Guards, rear fan and grill
  • BLADES
    • Bulldozer arrangement is included in the standard equipment. Bulldozer blades are optional.
  • FLUIDS
    • Antifreeze, premixed 50% concentration of extended life coolant with freeze protection to –34° C (–29° F)
  • OTHER STANDARD EQUIPMENT
    • Auto Blade Positioner (ABP)
    • Demand fan/swing out (hydraulic reversible)
    • Doors, service access locking
    • Ecology drains for engine, radiator, hydraulic tank
    • Electronic clutch pressure control and remote mounted pressure taps
    • Emergency platform egress
    • Engine, crankcase, 250 hour interval with CJ-4 oil
    • Fuel tank, 793 L (210 gal)
    • Hitch, drawbar with pin
    • Hoses, Cat XT™
    • Hydraulic oil cooler
    • Hydraulic, steering and brake filtration/screening system
    • Oil sampling valves
    • Product Link
    • Stairways, fixed-L/R (rear access)
    • Steering, load sensing
    • Vandalism protection caplocks
    • Venturi stack
Optional Equipment
  • Various blades:
    • Straight blade
    • U-blade
    • Semi U-blade
  • Various tip and wheel arrangements:
    • Paddle
    • Plus
    • Diamond
