5.0 m3 (6.5 yd3) Pin On Light Material Bucket With Bolt-On Cutting Edge

US
Metric

Overview

Cat® Loader Light Material Buckets are specially designed for maximum efficiency and increased capacity when loading light, loosely-packed materials.
Width
108.10 in
2747.00 mm
Height
66.40 in
1687.00 mm
Weight
3298.10 lb
1496.00 kg
Length
68.30 in
1735.00 mm
Capacity
6.50 yd³
5.00 m³
Base Edge Thickness
1.00 in
25.00 mm
Interface Type
Pin On
Features

Application

Designed for carrying light, loosely-packed materials.

Versatile Design

Easily hauls, loads, digs and piles light materials such as snow, hay or woodchips.

High Capacity Design

Increased capacity up to 60% over standard buckets.

Material Density Rating

Designed for loading material with a density of 1300 lb/yd3 (770 kg/m3) or less.

Optional Top Clamp

Optional full-width top clamp tightly holds loose materials such as hay with minimum spillage, and holds large round bales securely.
