Engine
Emissions
U.S. EPA Tier 4 Final/EU Stage IV/Korea Tier 4 Final
Engine Power - Maximum - At 2,200 rpm - SAE J1995
Engine Power - Maximum - At 2,200 rpm - ISO 14396
Engine Power - Maximum - At 2,200 rpm - ISO 14396 (DIN)
Net Power - 1,800 rpm - ISO 9249/SAE J1349
Net Power - 1,800 rpm - ISO 9249/SAE J1349 (DIN)
Weights
Multi-Shank Ripper - With 3 Shanks
Blades
Width - LGP VPAT - Foldable
Capacity - LGP VPAT - Foldable
Transmission
Undercarriage
Ground Contact Area* - XL
Ground Contact Area* - LGP
Service Refill Capacities
Sustainability - Sound and Vibration Levels
Note
*Values are for an experienced operator in a dozing application, consult the Operating and Maintenance Manual for details.
Sound Levels - Average Exterior Sound Pressure Level - SAE J88:2006
Sound Levels - Maximum Sound Power Level - 2000/14/EC
110.00 dB(A)
110.00 dB(A)
Sound Levels - Dynamic Operator Sound Pressure Level (LpA) - ISO 6396:2008
Vibration Levels - Maximum Hand/Arm* - ISO 5349:2001
Vibration Levels - Maximum Whole Body* - ISO/TR25398:2006
Vibration Levels - Seat Transmissibility Factor - ISO 7096:2000 - Spectral Class EM6
Ripper
Maximum Clearance Raised - Shank Tip
Maximum Penetration Force - LGP
Maximum Penetration Force - XL
Maximum Pry-out Force - LGP
Maximum Pry-out Force - XL
Shank Section
73 mm × 176 mm (2.9 in × 6.9 in)
Beam Cross Section
216 mm × 254 mm (8.5 in × 10.0 in)
Maximum Penetration - LGP
Winch
Cable Ferrule Size (O.D. × Length)
54 mm × 67 mm (2.13 in × 2.63 in)
Maximum Bare Drum - Line Pull*
Maximum Bare Drum – Line Speed
141.00 ft/min
43.00 m/min
Maximum Full Drum - Line Pull*
Maximum Full Drum – Line Speed
217.00 ft/min
66.10 m/min
Rope Diameter (recommended)
Note (1)
*Weight: Includes pump, operator controls, oil, mounting brackets and spacers.
Drum Capacity - 22 mm (0.88 in)
Standards
FOPS
FOPS (Falling Object Protective Structure) meets ISO 3449-2005 Level II.
ROPS
ROPS (Rollover Protective Structure) offered by Caterpillar for the machine meets ROPS criteria ISO 3471:2008.
Brakes
Brakes meet the standard ISO 10265:2008.
Service Refill Capacities
Roller Frames XL/LGP - Each
Hydraulic Controls - Pressures
Maximum Implement Operating Pressure
Maximum Steering Operating Pressure
Hydraulic Controls – Pump
Pump Output – Implement
33.50 gal/min
127.00 L/min
Pump Output – Steering
36.20 gal/min
137.00 L/min
Lift Cylinder Flow
33.50 gal/min
127.00 L/min
Tilt Cylinder Flow
23.80 gal/min
90.00 L/min
Ripper Cylinder Flow
33.50 gal/min
127.00 L/min
Angle Cylinder Flow – VPAT
33.50 gal/min
127.00 L/min
Transmission
Maximum Drawbar Pull - 1.0 Forward
Maximum Drawbar Pull - 2.0 Forward
Maximum Drawbar Pull - 3.0 Forward
Undercarriage
Note
All dimensions with SystemOne undercarriage.
Winch
Note (2)
Slow and standard speed winches are available.
Engine
Note
Net power advertised is the power available at the engine flywheel when the engine is equipped with the air cleaner, muffler, alternator, cooling fan at maximum speed.
Note
No derating required up to 3000 m (9,840 ft) altitude, beyond 3000 m (9,840 ft) automatic derating occurs.
Note
All non-road Tier 4 Interim and Final, Stage IIIB and IV, and Korea Tier 4 Final diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm EPA/10 ppm EU (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations.
Note
Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241.
Weights
Operating Weight – XL Fine Grading
Operating Weight - XL Waste Handler
Operating Weight - LGP Waste Handler
Shipping Weight – XL Fine Grading
Shipping Weight - XL Waste Handler
Shipping Weight - LGP Waste Handler
Note
Operating Weight: Includes EROPS, A/C, lights, VPAT dozer, transmission, drawbar, engine enclosure, 3-valve hydraulics, 100% fuel, and Cat Comfort Series Air Suspension Seat and operator.
Note
Shipping Weight: Includes EROPS, A/C, lights, VPAT dozer, transmission, drawbar, engine enclosure, 3-valve hydraulics, 5% fuel, and Cat Comfort Series Air Suspension Seat.
Undercarriage
Shoe Width - XL - Fine Grading
Shoes/Side - XL - Fine Grading
Grouser Height - XL - Fine Grading
Track Gauge - XL - Fine Grading
Track on Ground - XL - Fine Grading
Ground Contact Area* - XL - Fine Grading
Ground Pressure* - XL - Fine Grading
Track Rollers/Side - XL - Fine Grading
Sound and Vibration - Cab
Sound Level Information (1)
The operator Equivalent Sound Pressure Level (Leq) is 81.5 dB(A) when “ANSI/SAE J1166 FEB2008” is used to measure the value for an enclosed cab. The measurement was conducted at 100% of the maximum engine cooling fan speed. This is a work cycle sound exposure level. The cab was properly installed and maintained. The test was conducted with the cab doors and the cab windows closed.
Sound Level Information (2)
Hearing protection may be needed when the machine is operated with an open operator station for extended periods or in a noisy environment. Hearing protection may be needed when the machine is operated with a cab that is not properly maintained, or when the doors and windows are open for extended periods or in a noisy environment.
Sound Level Information (3)
The average exterior sound pressure level is 85.5 dB(A) when the “SAE J88 FEB2006 – Constant Speed Moving Test” procedure is used to measure the value for the standard machine. The measurement was conducted under the following conditions: distance of 15 m (49.2 ft) and “the machine moving forward in an intermediate gear ratio.”
Sound Level Information for Machines in European Union Countries and in Countries that Adopt the “EU Directives.” The information below applies to only the machine configurations that have the “CE” mark on the Product Identification Plate. (1)
The declared dynamic operator sound pressure level is 76 dB(A) when “ISO 6396:2008” is used to measure the value for an enclosed cab. The measurement was conducted at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds. The cab was properly installed and maintained. The measurement was conducted with the cab doors and the cab windows closed. NOTE: This dynamic operator sound pressure level is associated to a 2 dB(A) uncertainty.
Sound Level Information for Machines in European Union Countries and in Countries that Adopt the “EU Directives.” The information below applies to only the machine configurations that have the “CE” mark on the Product Identification Plate. (2)
If equipped, the certification label – 110 dB(A) – is used to verify the environmental sound certification of the machine to the requirements of the European Union. The value that is listed on the label indicates the guaranteed exterior sound power level (LWA) at the time of manufacture for the conditions that are specified in “2000/14/EC.” Your machine may have a different value.
Air Conditioning System
Air Conditioning
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes.
Engine
Emissions
U.S. EPA Tier 4 Final/EU Stage IV/Korea Tier 4 Final
Transmission
Service Refill Capacities
Weights
Undercarriage
Ripper
Shank Section
73 mm × 176 mm (2.9 in × 6.9 in)
Weight - With Three Shanks
Winch
Cable Ferrule Size - O.D. × Length
54 mm × 67 mm (2.13 in × 2.63 in)
Maximum Bare Drum - Line Speed
141.00 ft/min
43.00 m/min
Maximum Full Drum - Line Speed
217.00 ft/min
66.10 m/min
Rope Diameter - Recommended
Standards
FOPS
FOPS (Falling Object Protective Structure) meets ISO 3449-2005 Level II.
ROPS
ROPS (Rollover Protective Structure) offered by Caterpillar for the machine meets ROPS criteria ISO 3471:2008.
Brakes
Brakes meet the standard ISO 10265:2008.
Transmission
Service Refill Capacities
Air Conditioning System
Air Conditioning
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes.
Engine
Note (1)
Net power advertised is the power available at the engine flywheel when the engine is equipped with the air cleaner, muffler, alternator, cooling fan at maximum speed.
Note (2)
No derating required up to 3000 m (9,840 ft) altitude, beyond 3000 m (9,840 ft) automatic derating occurs.
Note (3)
All non-road Tier 4 Interim and Final, Stage IIIB and IV, and Korea Tier 4 Final diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm EPA/10 ppm EU (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations.
Note (4)
Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241.
Hydraulic Controls - Pump
Angle Cylinder Flow - VPAT
33.50 gal/min
127.00 l/min
Lift Cylinder Flow
33.50 gal/min
127.00 l/min
Pump Output - Implement
33.50 gal/min
127.00 l/min
Pump Output - Steering
36.20 gal/min
137.00 l/min
Ripper Cylinder Flow
33.50 gal/min
127.00 l/min
Tilt Cylinder Flow
23.80 gal/min
90.00 l/min
Service Refill Capacities
Transmission
Undercarriage
Note (2)
All dimensions with SystemOne undercarriage.
Weights
Note (1)
Operating Weight: Includes EROPS, A/C, lights, VPAT dozer, transmission, drawbar, engine enclosure, 3-valve hydraulics, 100% fuel, and Cat Comfort Series Air Suspension Seat and operator.
Note (2)
Shipping Weight: Includes EROPS, A/C, lights, VPAT dozer, transmission, drawbar, engine enclosure, 3-valve hydraulics, 5% fuel, and Cat Comfort Series Air Suspension Seat.
Operating Weight - XL Fine Grading
Shipping Weight - XL Fine Grading
