2776mm (109in) Millyard Fork

US
Metric

Overview

Width
109.00 in
2776.00 mm
Width Over Tine
108.00 in
2741.00 mm
Width Between Tines
87.00 in
2217.00 mm
Tine Length
72.00 in
1829.00 mm
Max. Clamp Opening
116.00 in
2951.00 mm
Min. Clamp Opening
23.00 in
582.00 mm
End Area
18.00 sq ft
1.70 sq m
Weight
8726.00 lb
3958.00 kg
Tip Type
Roller
Width
109.00 lb/in
2776.00 mm
Width - Over Tines
108.00 lb/in
2741.00 mm
Width - Between Tines
87.00 lb/in
2217.00 mm
Tine Length
72.00 lb/in
1829.00 mm
Maximum Clamp Opening
116.00 lb/in
2951.00 mm
Minimum Clamp Opening
23.00 lb/in
582.00 mm
End Area
18.00 ft²
1.70 m²
Weight
8726.00 lb
3958.00 kg
