Overview

To keep your business on firm footing, you need undercarriage systems and components that propel your machines over any type of terrain— and through every operational challenge. Leveraging decades of experience in mining, excavation and material handling, the Cat® brand utilizes its storied industry roots to deliver high productivity, durability and reliability. And to ensure the proper fit, our team of engineers will work with you to choose the right undercarriage for your application that will help yield low operating costs, long service life and great value.

Specs

Upper Model Pairing
323 Upper
Typical Drill Rig Weight Range
28-37 mtons
U/C Weight
10.60 t
10.60 t
Track Gauges K1/K2
1950/3050
Lower Width (retracted)
2550.00 mm
2550.00 mm
Lower Width (extended)
3650.00 mm
3650.00 mm
Shoe Width
600.00 mm
600.00 mm
Wheel Base
3830.00 mm
3830.00 mm
Shoe Offset
No
Bearing Riser Height
854.00 mm
854.00 mm
Max. Tractive Eff.
39.00 t
39.00 t
Machine Speed
2.00 km/h
2.00 km/h
