Overview

To keep your business on firm footing, you need undercarriage systems and components that propel your machines over any type of terrain— and through every operational challenge. Leveraging decades of experience in mining, excavation and material handling, the Cat® brand utilizes its storied industry roots to deliver high productivity, durability and reliability. And to ensure the proper fit, our team of engineers will work with you to choose the right undercarriage for your application that will help yield low operating costs, long service life and great value.

Specs

Upper Model Pairing
336/340 Upper
Typical Drill Rig Weight Range
50-63 mtons
U/C Weight
18.00 t
18.00 t
Track Gauges K1/K2
2250/3700
Lower Width (retracted)
3000.00 mm
3000.00 mm
Lower Width (extended)
4450.00 mm
4450.00 mm
Shoe Width
720.00 mm
720.00 mm
Wheel Base
4600.00 mm
4600.00 mm
Shoe Offset
No
Bearing Riser Height
1078.00 mm
1078.00 mm
Max. Tractive Eff.
44.00 t
44.00 t
Machine Speed
2.17 km/h
2.17 km/h
