Overview

Specifications

Engine Model
Cat C7.1 Tier 4 Final
Gross Power
225 hp / 168 kW
Engine Speed
2200 rpm
Fuel Capacity
99.8 gal / 378 L
DEF Capacity
5.0 gal / 19 L
Wheelbase
149.4" / 3796 mm
Weight
45,888 lb / 20,814 kg
Transport Width
10' 7" / 3.21 m
Transport Height
11' 1" / 3.39 m
Transport Length
27' 10" / 8.47 m
Ground Clearance
21.7" / 550 mm
HD Box Grapple Capacity
16.6 ft² / 1.54m²
HD Box Grapple Opening
127.0" / 3226 mm
Biomass Grapple Capacity
18.0 ft² / 1.67 m²
Biomass Grapple Opening
145.0" / 3683 mm
Standard Equipment

POWERTRAIN

  • Cat C7.1 engine certified to EPA Tier 4 Final
  • Primary and secondary fuel filters, including water separator
  • Electric fuel priming pump
  • Electric fuel transfer pump
  • Centrifugal engine air pre-cleaner
  • 2-Stage engine air cleaner
  • Cross-flow cooling system with swing out cores
  • Swing out air conditioner condenser and fuel cooler
  • Hydraulically driven, on demand reversing cooling fan
  • Powershift transmission with lock-up torque converter
  • Cat HD axles, approved for odd size dual tires up to 30.5L-32 with 24.5L-32
  • and wide tires up to 73-44 with chains
  • Independent front and rear differential locks
  • Lubed for life universal joints and HD drive shafts
  • Enclosed disc service brakes
  • Spring applied, hydraulically released parking brake

OPERATOR ENVIRONMENT

  • Enclosed OPS/FOPS/ROPS certified cab
  • High capacity HVAC system
  • Air suspension seat with harness seat belt
  • AM/FM/Bluetooth Radio
  • 24V to 12V converter and a 12V power port
  • 2 Beverage holders
  • Computerized Monitoring System

HYDRAULICS

  • Load-sense hydraulics
  • Variable displacement pumps
  • High performance, multi-functioning main control valve
  • In-tank return filter

ELECTRICAL

  • 115 ampere alternator
  • 24-volt electrical system with 2 12-volt batteries
  • Main disconnect switch with Diesel Exhaust Fluid (DEF) purge indicator light
  • Jump start posts
  • Product Link Ready

OTHER STANDARD EQUIPMENT

  • Heavy-duty frames
  • Dual tapered roller bearing upper and lower center hitch
  • Heavy-duty limb risers
  • Wide blade
  • Ecology drains (engine oil, engine coolant, hyd tank, axles, transmission)
  • Tilt Cab
  • Segregated engine/CEM and cooling compartments
  • Single side engine service
  • S·O·S sampling ports
Optional Equipment

OPTIONAL EQUIPMENT

  • Dual function arch/boom and grapple head
  • Cable arch and extreme duty fenders
  • Industrial arrangement
  • HD Box Section or Biomass Plate Grapple Tongs
  • Winch Ready, Retrieval Winch or Logging Winch
  • Grapple Fenders
  • Standard or Deluxe Cab
  • Wheel or Joystick Steering
  • Standard, Deluxe or Premium Working Lights
  • Window Screens
  • Pressurized Water Tank
  • 30.5L-32 NOAW Tires - 126.6" (3216 mm)
  • 30.5L-32 Tires - 133.3" (3386 mm), Approved for Chains
  • 30.5L-32 2X Ring Tires - 126.6" (3216 mm)
  • 35.5L-32 NOAW Tires - 139.1" (3533 mm)
  • 35.5L-32 Tires - 145.8" (3703 mm), Approved for Chains
  • Ether Starting Aid
  • Electric Hydraulic Oil Fill Pump
  • Front and Rear Window Wipers
  • Secondary Steering
