Cat Advansys Adapters
CAT ADVANSYS SYSTEM BENEFITS SUMMARY:
- Improved Productivity: Exclusive tip and adapter features result in the highest productivity Cat system
- Enhanced Reliability: Strongest, most robust adapters Caterpillar® has ever produced
- Hammerless Installation: Quickest hammerless tip removal and installation with a 3/4 inch retainer lock that requires no special tools
- Simplify Installation: Integrated retention components mean no more searching for pins or retainers
- Simplify Retrofitting: Easy upgrading because Advansys adapters drop into the same space as K series
- Simplify Ordering: One part number to order when changing a set of tips
CAT ADVANSYS SYSTEM PERFORMANCE:
- Exclusive performance features such as tapered tip sides offer less drag and higher productivity
- New and optimized tip shapes put wear material where you need it most
CAT ADVANSYS SYSTEM RELIABILITY:
- Stronger adapter noses are designed with up to a 50% stress reduction
- Improved adapter nose geometry reduces sliding wear on adapter nose surfaces extending the life of the adapter
- Improved tip shapes shadow the adapter straps and welds for longer adapter life
- Top covers available for double strap adapters and full adapter covers available for high abrasion flush mount adapters
CAT ADVANSYS HAMMERLESS INSTALLATION AND REMOVAL:
- Half turn of retention locks and unlocks the CapSure retention
- Only a 1/2” or 3/4” breaker bar is required to change the tips
- Retention components come installed in tips
Cat Advansys for Wheel Loaders
Contact Us
Heavy Abrasion
- Use in easy to penetrate high abrasive materials
- Lower penetration ability
- Heavy wear pad for long wear life
Heavy Penetration
- Use in hard to penetrate high abrasive materials
- Very good penetration
- Heavy wear pad for long wear life
Heavy Duty
- Use in moderate abrasive materials
- Good penetration
- Single top self-sharpening cavity
General Purpose Loader
- Use in low abrasive materials
- Good penetration
- Single top self-sharpening cavity
Coal
- Use in low abrasive materials like coal seams
- Use on loaders to produce a smoother floor
Penetration Plus
- Use in hard to penetrate, moderate to high abrasive materials
- Very good penetration
- Stays sharp
Penetration
- Use in hard to penetrate, low abrasive materials
- Very good penetration
- Stays sharp
Cat Advansys for Excavators
Contact Us
Heavy Duty
- Use in moderate abrasive materials
- Good penetration
- Single top self-sharpening cavity
General Purpose Excavator
- Use in low abrasive materials
- Good penetration
- Single top-self-sharpening cavity
Wide
- Use on excavators to produce a smoother floor
- Reduced penetration
- Less bucket spillage between tips
Penetration Plus
- Use in hard to penetrate, moderate to high abrasive materials
- Very good penetration
- Stays sharp
Penetration
- Use in hard to penetrate, low abrasive materials
- Very good penetration
- Stays sharp
Spike
- Use in very hard to penetrate, low abrasive materials
- Maximum penetration
- Cross section to maintain sharpness
Double Spike
- Use in hard to penetrate, fracturable materials
- Excellent penetration
- Use at corner positions with spike centers
