Overview

Specifications

Engine Model
Cat C9.3 Tier 4 Final
Gross Power
298 hp / 222 kW
Engine Displacement
568 in³ / 9.3 L
Weight (no head)
79,221 lb / 35,934 kg
Maximum Flow
322 gpm / 1220 L/min
Max. Reach (w/ 201 saw)
26’ 10” / 8.19 m
Lift at Max. Reach (no head)
13,918 lb / 6313 kg
Tractive Effort
81,229 lbf / 36,845 kgf
Undercarriage Size
336 HD HEX
Undercarriage Pitch
8.5” / 216 mm
Ground Clearance
35” / 881 mm
Track Gauge
114” / 2883 mm
Track Length
191” / 4856 mm
Leveling System Capability
21° Forward / 11° Side-to-Side
Fuel Tank Capacity
216 gal / 819 L
Engine Oil Capacity
10.6 gal / 40 L
Hydraulic System Capacity
79.8 gal / 302 L
Transport Width
11’ 11” / 3.62 m
Height
12’ 11” / 3.94 m
Length (boom ext., w/201 saw)
34’ 1” / 10.39 m
Length (boom tuck., no head)
25’ 7” / 7.81 m
Standard Equipment

POWERTRAIN

  • Cat C9.3 engine certified to EPA Tier 4 Final
  • Primary, secondary, and tertiary fuel filters, including water separator
  • Side-by-side radiator and oil cooler
  • Swing out air-to-air cooler and air conditioner condenser
  • Removable debris screen
  • Centrifugal engine air pre-cleaner
  • Under-hood 2-stage engine air cleaner
  • Variable pitch, reversing fan with guard
  • Heavy-duty starter and ether aid

UNDERCARRIAGE

  • Three-cylinder leveling system
  • Heavy-duty variable gauge track roller frames
  • Grease-lubricated 336 HD HEX track
  • Straddle mounted carrier rollers
  • Heavy-duty bottom track rollers
  • Heavy-duty recoil mechanisms
  • Full length track shoe support
  • Heavy-duty travel motor and swivel guards
  • Towing eyes on base frame

HYDRAULICS

  • One hydraulic pump group for implement functions
  • One hydraulic pump group for track functions
  • Dedicated attachment pump for head functions
  • Dedicated saw pump
  • High-performance hydraulic return filters
  • 325 size, high torque swing drive
  • Swing cushion valve and automatic swing parking brake
  • Electric hydraulic oil fill pump
  • Spare hose storage area


ELECTRICAL

  • 115 ampere alternator
  • 24-volt electrical system with 2 12-volt batteries
  • 9 LED working lights and 2 LED service lights
  • Horn and travel alarm
  • Secondary engine shut off switch
  • Product Link™ ready

OPERATOR ENVIRONMENT

  • Enclosed FOPS/ROPS/OPS/OR-OSHA/WCB certified cab
  • Air suspension with integrated joysticks and head rest
  • Left-hand tilt console
  • Retractable 4-point seat belt
  • Touchscreen display monitor and programmable operator controls
  • Scratch resistant polycarbonate windows
  • Reverse slope 1.25” (32 mm) front windshield
  • Front window emergency escape
  • Skylight
  • Left-side fresh air window
  • Pressurized cab with filtered ventilation
  • Heater / air conditioner / defroster
  • Radio ready with speakers
  • Mount locations for CB radio and other accessories
  • Behind seat storage tray
  • Three cup holders, two USB sockets, and literature holder

OTHER STANDARD EQUIPMENT

  • Heavy-duty hood enclosure
  • Heavy-duty counterweight with machine level engine enclosure access
  • Heavy-duty doors, covers, and bottom guards
Optional Equipment
  • Standard feller buncher boom and stick
  • Intermittent saw boom and stick
  • Boom and stick omission
  • 30 or 50 mm counterweight
  • Standard or extended roller frames (eleven bottom rollers)
  • Standard or star carrier rollers
  • 24” (600 mm) SG 336 HD HEX Track
  • 28” (710 mm) SG or DG 336 HD HEX Track
  • Std. or deluxe cab (heated-cooled seat / satellite radio / sun screens)
  • Standard deluxe lights (14 LED working lights)
  • Standard, cold, or arctic starting aid
  • 201 continuous saw w/ partial or full tilt - 22.5” (572 mm)
