610 mm (24 in) Heavy Duty Rock Bucket

US
Metric

Overview

Heavy Duty Rock Buckets for Cat® Mini Excavators are built for aggressive bucket loading in highly abrasive applications such as severe rock.
Width
24.00 in
610.00 mm
Rated Capacity
8.10 ft3
229.40 L
Weight
427.70 lb
194.00 kg
Base Edge Thickness
1.00 in
25.00 mm
Tip Radius
40.00 in
1015.00 mm
Width
24.00 in
610.00 mm
Rated Capacity
8.10 yd³
229.40 m³
Weight
427.70 lb
194.00 kg
Base Edge Thickness
1.00 in
25.00 mm
Tip Radius
40.00 in
1015.00 mm
Capacity
8.10 ft³
229.40 l
Interface Type
Pin On
Features

Application

Designed for aggressive applications and coarse aggregate removal. Used in demanding applications such as rock and concrete removal.

Designed For Extreme Duty

Similar to heavy duty buckets but with thicker wear plates for use in highly abrasive and high impact applications.

Bucket Design

Formed back wrapper design enhances bucket loading ability and production.

Superior Bucket Fill

Optimum wrapper angle and no sharp corners promote superior bucket fill and reduce material packing.
