610 mm (24 in) pin on Standard Duty Bucket

US
Metric

Overview

Cat® Standard Duty Buckets for Backhoe Loaders are designed for use in easy-to-penetrate, low impact, moderately abrasive soils.
Width
24.00 in
610.00 mm
Rated Capacity
6.20 ft3
176.00 L
Weight
291.00 lb
132.00 kg
Base Edge Thickness
0.80 in
20.00 mm
Tip Radius
35.80 in
909.00 mm
Width
24.00 in
610.00 mm
Rated Capacity
6.20 ft³
176.00 l
Weight
291.00 lb
132.00 kg
Base Edge Thickness
0.80 in
20.00 mm
Tip Radius
36.00 in
909.00 mm

Specifications

Capacity
6.20 ft³
176.00 l

Interface Type

Interface Type
Pin on

Capacity
6.20 ft³
176.00 l
Interface Type
Pin on
Features

Application

Designed for general light duty excavation in soft soil or clay.

Bucket Shape

Enhanced bucket shape allows material to flow more easily. Tapered bucket sidewalls allow for easy dumping of sticky material.

Rugged Design

Cat® Buckets are designed for superior productivity, reliability and long life.
