US
Metric

Overview

Length
77.60 in
1972.00 mm
Height
51.00 in
1296.00 mm
Width
31.20 in
739.00 mm
Jaw Depth
25.40 in
645.00 mm
Jaw Width, fixed
11.80 in
299.00 mm
Jaw Opening - max.
26.90 in
682.00 mm
Cutter Length
15.00 in
382.00 mm
Weight (housing, jaw and bracket)
42533.00 lb
1933.00 kg
Weight (jaw only)
1586.00 lb
721.00 kg
Cycle time
2.60 Seconds
2.60 Seconds
Crushing Force, tooth tip
80.80 Sh Ton
719.00 kN
Crushing Force, cutter tip
120.80 Sh Ton
1075.00 kN
Crushing Force, primary cutter
261.20 Sh Ton
2325.00 kN

Dimensions - Housing + Jaw

Length
78.00 in
1972.00 mm
Height
51.00 in
1296.00 mm
Width
31.00 in
793.00 mm

Dimensions - Jaw

Jaw Depth
25.00 in
645.00 mm
Jaw Width - Fixed
12.00 in
299.00 mm
Jaw Opening - Maximum
27.00 in
682.00 mm
Cutter Length
15.00 in
382.00 mm

Weight

Weight - Housing, Jaw and Bracket
0.00 lb
0.00 kg
Weight - Jaw Only
1586.00 lb
721.00 kg

Performance

Cycle Time
2.60 s
2.60 s
Crushing Force - Tooth Tip
90.00 Sh Ton
802.00 kN
Crushing Force - Cutter Tip
130.00 Sh Ton
1158.00 kN
Crushing Force - Primary Cutter
295.00 Sh Ton
2622.00 kN

Dimensions - Jaw

Jaw Width - Moveable
4.00
104.00
