2036 mm (80 in) Multi-Purpose Bucket With Bolt-On Cutting Edge And Spill Guard

US
Metric

Overview

Cat® Multi-Purpose Buckets for Cat Skid Steer Loaders and Compact Track Loaders are extremely durable buckets, ideal for a wide variety of tasks in construction, landscaping, industrial and demolition applications.
Width
80.20 in
2036.00 mm
Capacity
0.52 yd³
0.40 m³
Weight
1016.00 lb
461.00 kg
Height
29.10 in
740.00 mm
Length
36.20 in
919.00 mm
Base Edge Thickness
0.70 in
19.00 mm
Cutting Edge Thickness
0.60 in
16.00 mm
Operating Pressure
3335.90 psi
23000.00 kPa
Jaw Opening
30.20 in
767.00 mm
Clam Angle
89 degrees
Interface Type
Skid Steer Coupler
Features

Application

Ideal for digging, dozing, clamping, back dragging, grading and leveling in construction, landscaping, industrial and demolition applications.

Excellent Clamping Force

Excellent clamping force lets you grasp large, irregularly shaped objects such as trees, loose stumps, brush, recycling debris and pipe, increasing the versatility of the machine.

Clam Jaw Opens a Full 89 Degrees

Bucket clam jaw opens a full 89 degrees, allowing the bucket to be used as a dozing blade.

Serrated Clam Side Edge

Serrated clam side edge provides a gripping surface to hold material.

Ground Engaging Tool Options

Base bucket also available with bolt-on cutting edge, bolt-on teeth and bolt-on tooth bar.
