762 mm (30 in) Pin Lock Heavy Duty Bucket

US
Metric

Overview

Cat® Heavy Duty Buckets for Backhoe Loaders are well suited for semi-rocky soil or where hard bank material must be broken out and removed.
Width
30.00 in
762.00 mm
Rated Capacity
9.90 ft3
280.00 L
Weight
443.10 lb
201.00 kg
Base Edge Thickness
1.00 in
25.00 mm
Tip Radius
35.80 in
909.00 mm
Width
30.00 in
762.00 mm
Rated Capacity
9.90 ft³
280.00 l
Weight
443.10 lb
201.00 kg
Base Edge Thickness
1.00 in
25.00 mm
Tip Radius
36.00 in
909.00 mm

Specifications

Capacity
9.90 ft³
280.00 l

Interface Type

Interface Type
Pin lock

Capacity
9.90 ft³
280.00 l
Interface Type
Pin Lock
Features

Application

Cat® Heavy Duty Buckets are well suited for semi-rocky soil or where hard bank material must be broken out and removed.

Bucket Shape

Enhanced bucket shape allows material to flow more easily. Tapered bucket sidewalls allow for easy dumping of sticky material.

Rugged Design

Cat Buckets are designed for superior productivity, reliability and long life.
