2007 mm (79 in) Dozer Blade

US
Metric

Overview

Cat® Dozer Blades are designed for rough and finish grading in dirt and gravel, and light dozing. With their 6-way capabilities, dozer blades are better suited for finish grade work in construction and landscaping applications.
Overall Width
79.00 in
2007.00 mm
Width - Fully Angled
69.00 in
1750.00 mm
Maximum Blade Angle (right/left of center)
±30 degrees
Tilt
±10 degrees
Blade Height
24.00 in
619.00 mm
Length
40.00 in
1028.00 mm
Weight
1082.00 lb
491.00 kg
Cutting Edge Thickness
0.63 in
16.00 mm
Required Hydraulics
Standard Flow
Required Hydraulic Flow
49-125 L/min (13-33 gpm)
Optimum Hydraulic Pressure
206-310 bar (3000-4500 psi)
Overall Width
79.00 in
2007.00 mm
Blade Height
24.00 in
619.00 mm
Cutting Edge Thickness
0.63 in
16.00 mm
Length
40.00 in
1028.00 mm
Maximum Blade Angle - Right/Left of Center
±30 degrees
Required Hydraulic Flow
49-125 L/min (13-33 gpm)
Tilt
±10 degrees
Weight
1082.00 lb
491.00 kg
Required Hydraulics
Standard Flow
Features

Application

Designed for rough and finish grading in dirt and gravel as well as for light dozing.

6-Way Capability

With their 6-way capabilities, dozer blades are better suited for finish grade work in construction and landscaping applications than angle blades.

VPAT Design

Track-type tractor variable power angle tilt (VPAT) design with simultaneous tilt and angling capability delivers superior control and maneuverability.

Easy Operation

Operation of Cat® Blade is easy with Cat joystick controls.

Replaceable Cutting Edge

Three-piece, replaceable, bolt-on, hardened cutting edge delivers long life and high performance.
