Overview

Ideal for interior demolition tasks, the compact S305 mounted on a Cat® Skid Steer Loader or Mini Excavator goes where no other demolition tool can. Remove conduits, wiring and interior fixtures.
Tip Force
43.30 Sh Ton
385.00 kN
Jaw Width - Moving
2.40 in
60.00 mm
Rotation Circuit - Maximum Flow
5.30 gal/min
20.00 l/min
Cutting Circuit - Maximum Relief Pressure
3626.00 psi
25000.00 kPa
Height
26.30 in
667.00 mm
Jaw Width - Fixed
9.10 in
230.00 mm
Cutting Circuit - Maximum Flow
15.90 gal/min
60.00 l/min
Jaw Depth
11.40 in
290.00 mm
Throat Force
203.70 Sh Ton
1812.00 kN
Apex Force
73.40 Sh Ton
653.00 kN
Jaw Opening
9.40 in
240.00 mm
Rotation Circuit - Maximum Relief Pressure
2900.80 psi
20000.00 kPa
Length
67.30 in
1709.00 mm
Width
15.40 in
390.00 mm
Cycle Time - Close
2.5 Seconds
Cycle Time - Open
3.5 Seconds
Weight
1212.50 lb
550.00 kg
Rotation
360 Degrees
Features

Jaw Design

Unique straight lower jaw design effectively enhances the cutting force by facilitating the spreading out of steel along the length of the jaw, maximizing the shear cutting force.

360° Rotation

Operator can spin the shear 360 degrees in either direction to quickly position the jaws for a cut.

Reversible Knives

The five main, side and front knives are fully reversible with four effective cutting edges.

Easy Maintenance

Large access panels on the top and bottom of the shear housing make it easier to service inside components.

Protected Cylinder

Design of the shear housing and cylinder rod guarding provides full protection of the cylinder throughout the complete cutting cycle.

Jaw Lockout Pin

Included with every shear to provide confidence that working in the jaw area is safe.

Speed Valve

Provides optimum flow regeneration to improve cycle times and machine productivity.

Mounting Options

Mounting options for the S308 Shear include a skid steer loader mounting bracket, a 7/8/9 ton stick mount, and a 5/6 ton boom mount bracket.

Included Service Kit

Each shear comes included with a service kit and tool box.
