Cat® Snow Blowers are designed for removing snow from streets, parking lots, driveways and sidewalks, making them ideal for various winter cleanup and maintenance applications.
Intake Width
63.50 in
1614.00 mm
Overall Width
73.90 in
1877.00 mm
996.50 lb
495.00 kg
Overall Height
72.60 in
1843.00 mm
Overall Length
37.40 in
951.00 mm
Required Hydraulics
High Flow XPS
Optimal Hydraulic Flow
125 L/min (33 gpm)
Optimal Hydraulic Pressure
280 bar (4061.1 psi)
Cutting Height
34.10 in
867.00 mm
Maximum Throw
40.00 ft
12.20 m
Auger Diameter
18.00 in
457.00 mm
Impeller Fan Diameter
25.00 in
635.00 mm
Impeller Fan Width
8.70 in
222.00 mm
Chute Rotation
270 degrees


Designed for removing snow from streets, parking lots, driveways and sidewalks.

Two Stage Design

Two-stage design uses auger and impeller to move a greater capacity of snow quickly and efficiently. Also, the auger and impeller are reversible which allows the operator to expel obstructions without exiting the machine.

Fan Style Impeller

Provides smooth operation and continuous flow of material in a variety of snow conditions.

Hydraulic Controls

Machine joysticks control chute and deflector. No additional wires or hardware to connect. Complete control with plug-n-play simplicity.

Chute Rotation and Deflector

270 degrees of rotation permits snow discharge to front or sides of machine preventing snow blow back on operator. Hydraulically controlled deflector makes it easy to control how far snow is thrown.

Offset Chute

Improves visibility and allows full range of motion on Compact Wheel Loader machines.

Adjustable Skid Shoes

Adjust height of cutting edge to suit the job needs.

Reversible Bolt-On Cutting Edge

Bolt-On reversible cutting edge adds extra life to the cutting edge and make replacement simple.

Rugged Access Step and Grab Handle

Wide steps with grating and large profile serrations provide better traction. Chute mounted grab handle allows stability when entering and exiting machine.
